Wholesale JIS SUS316 stainless steel welded tubing Supplier, Quotes

Stianless Steel Pipe /TUBE 1. : Grade :201 202 304 304l 316 316l 409 409H 410 430 etc 2. Standard:ASTM DIN JIS AISI GB 3.Surface: 2B BA NO.4 Mirror 320# 380# 400#600# 800# 4.Length :6M 11.5 M 12M or As Per your requirment. 5.OD :Round Tube 9.52-219MM Retangle :10*10-150-150 6.Inner packing :Plastic Bag 7.Outer Packing: Carton /Woven/Wooden Packaging 8.Od:+/- 0.2mm, Thickness: +/- 0.02mm

Send Inquiry

Product Description

JIS SUS316 Stainless Steel Welded Tubing

stainless steel coil tube stainless steel tube coil stainless steel coil tubing stainless steel coil pipe stainless steel coil tube suppliers stainless steel coil tube manufacturers stainless steel pipe coil

■ Specification Details

Item

Stainless steel welded polishing pipe

Type

Welded

Standard

EN, ASTM A269 A554, JIS, DIN

Grade

201, 202, 304, 304L, 316, 316L, 409, 430, etc.

Size

Round pipe: OD 8-219mm
Square Pipe: OD 10x10mm - 150x150mm
Rectangle Pipe: 10x20mm to 120x180mm

Thickness

0.2 - 4.0mm

Pipe Surface

180G, 320G, 400G, 500G, 600G, Satin, hairline, 2B, BA, mirror, 8K

Pipe Length

5.8m, 6M, 11.85M, 12m

■ Applications

Decoration Usage: Road, bridge handrail, railing, bus stop, airport, and gym.
Construction: Structural elements and ornament designs.
Industry Area: Petroleum, food, chemical, paper, fertilizer, fabric, aviation, and nuclear industries.

■ Size Chart Specifications

Square Steel Tube (mm)	Rectangular Steel Tube (mm)	Round Steel Tube (mm)
10×10×0.6~3.0	10×20×0.6~3.0	6x0.6~1.0
15×15×0.6~3.0	20×30×0.6~3.0	12x0.6~1.5
20×20×0.6~3.0	20×40×0.6~3.0	13x0.6~1.5
25×25×0.6~3.0	25×50×0.6~3.5	16x0.6~2.0
30×30×0.6~3.5	30×50×0.6~3.5	19x0.6~3.0
40×40×0.6~3.5	40×60×0.6~3.5	20x0.6~3.0
50×50×0.6~3.5	40×80×0.6~3.5	22x0.6~3.0
60×60×0.6~3.5	60×80×1.0~6.0	25x0.6~3.0
70×70×0.6~3.5	50×100×1.0~6.0	27x0.6~3.0
75×75×0.6~3.5	60×120×1.0~6.0	32x0.6~3.0
80×80×1.0~6.0	80×120×2.0~8.0	40x0.6~3.5
100×100×2.0~8.0	80×160×2.0~8.0	38x0.6~3.0
120×120×2.0~8.0	100×150×2.0~8.0	48x0.6~3.5
150×150×2.0~8.0	100×200×2.0~8.0	60x0.6~3.5
200×200×4.0~16.0	150×250×4.0~12.0	76x0.6~3.5
250×250×4.0~16.0	200×300×4.0~16.0	89x1.0~6.0
300×300×4.0~16.0	300×400×4.0~16.0	104x1.0~6.0
400×400×4.0~16.0	300×500×4.0~16.0	114x1.0~6.0

■ Chemical Composition (Austenitic Grades)

Grade	Composition, %
Grade	C (max)	Mn (max)	P (max)	S (max)	Si (max)	Ni	Cr	Mo	Ti	Cb + Ta
301	0.15	2.00	0.040	0.030	1.00	6.0–8.0	16.0–18.0	...	...	...
302	0.15	2.00	0.040	0.030	1.00	8.0–10.0	17.0–19.0	...	...	...
304	0.08	2.00	0.040	0.030	1.00	8.0–11.0	18.0–20.0	...	...	...
304L	0.035A	2.00	0.040	0.030	1.00	8.0–13.0	18.0–20.0	...	...	...
305	0.12	2.00	0.040	0.030	1.00	10.0–13.0	17.0–19.0	...	...	...
309S	0.08	2.00	0.040	0.030	1.00	12.0–15.0	22.0–24.0	...	...	...
309S-Cb	0.08	2.00	0.040	0.030	1.00	12.0–15.0	22.0–24.0	...	...	B
310S	0.08	2.00	0.040	0.030	1.00	19.0–22.0	24.0–26.0	...	...	...
316	0.08	2.00	0.040	0.030	1.00	10.0–14.0	16.0–18.0	2.0–3.0	...	...
316L	0.035A	2.00	0.040	0.030	1.00	10.0–15.0	16.0–18.0	2.0–3.0	...	...
317	0.08	2.00	0.040	0.030	1.00	11.0–14.0	18.0–20.0	3.0–4.0	...	...
321	0.08	2.00	0.040	0.030	1.00	9.0–13.0	17.0–20.0	...	C	...
330	0.15	2.00	0.040	0.030	1.00	33.0–36.0	14.0–16.0	...	...	...
347	0.08	2.00	0.040	0.030	1.00	9.0–13.0	17.0–20.0	...	...	B
429	0.12	1.00	0.040	0.030	1.00	0.50 max	14.0–16.0	...	...	...
430	0.12	1.00	0.040	0.030	1.00	0.50 max	16.0–18.0	...	...	...
430-Ti	0.10	1.00	0.040	0.030	1.00	0.075 max	16.0–19.5	...	5 × C min	...
...	...	...	...	...	...	...	...	...	0.75 max	...

■ Coiled Tubing Material Grade Equivalents

U.S.A. (AISI)	Germany (DIN)	Germany (W.N.)	France (AFNOR)	Japan (JIS)	Italy (UNI)	Sweden (SIS)	U.K. (BSI)	E.U. (EN)
201	...	...	...	SUS 201	...	...	...	...
301	X 12 CrNi 17 7	1.4310	Z 12 CN 17-07	SUS 301	X 12 CrNi 1707	23 31	301S21	X 12 CrNi 17 7
302	X 5 CrNi 18 7	1.4319	Z 10 CN 18-09	SUS 302	X 10 CrNi 1809	23 31	302S25	X 10 CrNi 18 9
303	X 10 CrNiS 18 9	1.4305	Z 10 CNF 18-09	SUS 303	X 10 CrNiS 1809	23 46	303S21	X 10 CrNiS 18 9
304	X 5 CrNi 18 10	1.4301	Z 6 CN 18-09	SUS 304	X 5 CrNi 1810	23 32	304S15	X 6 CrNi 18 10
304L	X 2 CrNi 18 11	1.4306	Z 2 CN 18-10	SUS 304L	X 2 CrNi 1911	23 52	304S11	X 3 CrNi 18 10
305	...	...	Z 8 CN 18-12	SUS 305	X 8 CrNi 1812	23 33	305S19	X 8 CrNi 18 12
316	X 5 CrNiMo 17 12 2	1.4401	Z 6 CND 17-11	SUS 316	X 5 CrNiMo 1712	23 47	316S31	X 6 CrNiMo 17 12 2
316L	X 2 CrNiMo 17 13 2	1.4404	Z 2 CND 17-12	SUS 316L	X 2 CrNiMo 1712	23 48	316S11	X 3 CrNiMo 17 12 2
321	X 6 CrNiTi 18 10	1.4541	Z 6 CNT 18-10	SUS 321	X 6 CrNiTi 1811	23 37	321S31	X 6 CrNiTi 18 10
347	X 6 CrNiNb 18 10	1.4550	Z 6 CNNb 18-10	SUS 347	X 6 CrNiNb 1811	23 38	347S31	X 6 CrNiNb 18 10
904L	...	1.4939	Z 12 CNDV 12-02	...	...	...	...	...
UNS31803	X 2 CrNiMoN 22 5	1.4462	...	...	...	...	...	...
409	X 6 CrTi 12	1.4512	Z 6 CT 12	SUH 409	X 6 CrTi 12	...	409S19	X 5 CrTi 12
410	X 6 Cr 13	1.4000	Z 10 C 13	SUS 410	X 12 Cr 13	23 02	410S21	X 12 Cr 13

■ Factory

■ Quality Advantage

The quality of our products for the control line in oil and gas sector is assured not just during the controlled manufacturing process but also by way of finished product testing. Typical tests include:

Non-destructive tests
Hydrostatic tests
Surface finish controls
Dimensional accuracy measurements
Flare and coning tests
Mechanical and chemical property testing

■ Capillary Tube Applications

Medical device industry
Temperature-guided industrial temperature control, sensors used pipe, tube thermometer
Pens care industry core tube
Micro-tube antenna, various types of small precision stainless steel antenna
With a variety of electronic small-diameter stainless steel capillary
Jewelry needle punch
Watches, picture components
Car antenna tube, bar antennas using tubes, antenna tube
Laser engraving equipment to use stainless steel tube
Fishing gear, accessories
Diet with stainless steel capillary
All types of mobile phone stylus and computer stylus
Heating pipe industry, oil industry
Printers, silent box needle
Pull a double-melt stainless steel tube used in window-coupled
A variety of industrial small diameter precision stainless steel tubes
Precision dispensing with stainless steel needles
Microphone, headphones and microphone to use stainless steel tube

■ Frequently Asked Questions (FAQ)

What are the primary applications of stainless steel capillary tubes?

Stainless steel capillary tubes are widely used in the medical device industry, temperature-guided industrial temperature controls, sensors, antennas, electronic components, jewelry needles, watches, stylus pens, heating pipes, and precision dispensing equipment.

What standards and grades are available for these welded tubes?

Our welded polishing pipes are produced in accordance with EN, ASTM A269, ASTM A554, JIS, and DIN standards. Available material grades include 201, 202, 304, 304L, 316, 316L, 409, and 430, among others.

What surface finishes can be applied to the stainless steel tubing?

We provide a wide array of surface finish options, including 180G, 320G, 400G, 500G, 600G, Satin, hairline, 2B, BA, mirror, and 8K.

What dimensional sizes do you offer for round, square, and rectangular pipes?

Our size ranges are as follows: Round pipes are available in OD 8-219mm; Square pipes range from OD 10x10mm to 150x150mm; and Rectangular pipes span from 10x20mm to 120x180mm. The thickness ranges from 0.2mm to 4.0mm.

How is the quality of the control line tubing verified?

Quality is verified through multiple rigorous finished product testing methods, including non-destructive tests, hydrostatic tests, surface finish controls, dimensional accuracy measurements, flare and coning tests, alongside comprehensive mechanical and chemical property evaluations.

What lengths of stainless steel welded pipes can be ordered?

Standard pipe lengths include 5.8m, 6m, 11.85m, and 12m to fit diverse structural and industrial shipping layouts.
