China astm a269 316L stainless steel control line tube Manufacturer, Manufacturers

1 / 1

China astm a269 316L stainless steel control line tube Manufacturer, Manufacturers

Sihe is Specialized in S31603/316L SS Control Line ,is a manufacturer of stainless steel control line S31603 Stianless Steel Hydraulic Control Line, TP 316L Coiled Tubing for Downhole Control Line . Because of the best quality and best price , We become a leader in stainless steel coiled tubings and capillary tubings’ field and Hydraulic Control Lines. Our quality of our products for the control line in oil and gas sector is assured not just during the controlled manufacturing process but also by way of finished product testing

Typical tests include:
Non-destructive tests
Hydrostatic tests
Surface finish controls Dimensional
accuracy measurements Flare and coning test
Mechanical and Chemical property test

We are also well known a269 316L SS Coiled Tubing Tube/Hydraulic Control Line , Manufacturer in China. Buy SS Coiled tubing at best price in China from us as compared to the market price. Sincerely look forward to cooperating with you.

Send Inquiry

Product Description

We produce 316 Stainless Steel Coil Tube 304l stainless steel coiled tubing control Line, which are polished, cleaned, passivated and are ready for immediate use. We are also well known SS Capillary Tubing and Hydraulic Control Lines' Manufacturer.

Related Products

ASTM 269 304 stainless steel Coiled Tubing trader stainless steel Coiled Pipe astm stainless steel coiled tubing cutter hplc stainless steel capillary tubing cutting stainless steel coiled tubing stainless steel 1/16 in. capillary tubing weight of stainless steel Capillary pipe per foot weight of stainless steel Coiled pipe stainless steel Coiled pipe for sale stainless steel Coiled Pipe weight per foot Stainless Steel Coiled tube 3/8”*0.049Inch Suppliers stainless steel Coiled tubing grades stainless steel Coiled tube HS code code 304L stainless steel Capillary pipe weight chart stainless steel Coiled tube metric 3/8”*0.5mm stainless steel Coiled tube properties stainless steel Coiled pipe section properties stainless steel Coiled Tube supplier exporter of stainless steel Coiled pipe 304 stainless steel Coiled pipes stainless steel Coiled tubes distributor 9.53*1.24 astm 321 stainless steel coiled tube stainless steel Coiled Tube manufacturer ss seamless Coiled Tube stockholder Stainless Steel Coiled Tubing Suppliers seamless Coiled Tubing exporter

Related Grades

Common Grades

TP304, TP304L, TP304H
TP321, TP321H
TP316L, TP316SS, TP316Ti
TP347, TP347H, TP317L
TP309S, TP310S, 904L

International Standards

Russian: 08X18H10, 03X18H11, 10X17H13M2T, 03X17H13M2, 12X18H10T, 08X18H10T, 08X18H12B
German: 1.4301, 1.4306, 1.4541, 1.4404, 1.4571, 1.4550
Japanese: SUS304, SUS304L, SUS321, SUS316L, SUS316Ti, SUS347, SUS800, SUS840

Specialty & Duplex Grades

Double-Grade: 304/304L, 316/316L, 321/321H, 347/347H
Super Duplex: 2205, 2304, S31803, S32750
Alloys: Inconel 600, 601, 625, 725, Incoloy 800, 800H, 800HT, 825, 901, 925, 926 Etc.

Standard Seamless Stainless Steel Coiled Tubing Control Line Sizes

ITEM	Material Grade	Size (mm)	Length (Mtrs)	Pressure (Mpa)
1	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/8″ × 0.025″	3200	80
2	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/8″ × 0.035″	3200	100
3	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/4″ × 0.035″	2000	100
4	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/4″ × 0.049″	2000	100
5	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	3/8″ × 0.035″	1500	80
6	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	3/8″ × 0.049″	1500	100
7	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/2″ × 0.049″	1000	80
8	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	1/2″ × 0.065″	1000	100
9	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 3mm × 0.7mm	3200	80
10	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 3mm × 0.9mm	3200	100
11	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 4mm × 0.9mm	3000	100
12	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 4mm × 1.1mm	3000	100
13	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 6mm × 0.9mm	2000	100
14	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 6mm × 1.1mm	2000	100
15	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 8mm × 1mm	1800	80
16	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 8mm × 1.2mm	1800	100
17	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 10mm × 1mm	1500	70
18	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 10mm × 1.2mm	1500	70
19	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 10mm × 2mm	500	100
20	304L, 304, 316, 316L, 904l, 310s, 625, 825, 2205, 2507	φ 12mm × 1.5mm	500	80

Seamless Stainless Steel Control Line Product Specifications

Specification Parameter	Details
Thickness	0.1 to 2mm
Material Grade	304, 304L, 316, 316L, 321, 316Ti, 904L, Duplex 2205, Monel400, Inconel 625, Inconel 825
Diameter	1.5 to 15 mm OD, 1/4inch, 3/8 inch in stock
Common Sizes in Stock	6.35mm1.24mm, 80.5mm, 80.8mm, 60.89mm, 81mm, 9.531.24mm, 10*1mm, etc.
Shape	Round
Unit Pipe Length	At least 8000 to 10,000 feet per coil (Length can be customized)
Range	All sizes and lengths available
Size	As per requirement
Surface	Bright annealed, polished soft inner and outer in clean condition
Pipe Fluid	Chemical, Water, Gas, Oil
Minimum Order Quantity	500 kgs

Related Applications & Uses

Medical Acupuncture with Coiled Tubing Control Line
High-pressure instrumentation with Coiled Tubing Control Line
Coal exploration with a stainless steel Control Line
Thermostat with Control Line
Beer machine with stainless steel Control Line
Drinking water equipment with stainless steel Control Line
Danfoss expansion valve with stainless steel Coiled Tubing Control Line
Specification Standards: Outer diameter: 0.3mm - 10mm | Tolerance: 0.005mm - 0.01mm

Frequently Asked Questions (FAQ)

What steel grades are available for your coiled control lines?

We offer a wide selection of grades, including standard common grades such as TP304, TP304L, TP321, TP316L, TP316Ti, TP347, and 904L. Additionally, we provide duplex steels (2205, 2304, S31803, S32750) and specialty alloys such as Inconel 600, Inconel 625, Incoloy 800H, and Incoloy 825.

What are the common sizes and pressure ratings for seamless stainless steel control lines?

Our control lines are available in multiple imperial and metric sizes, ranging from 1/8″ to 1/2″ in outer diameter (or φ3mm to φ12mm metric), with wall thicknesses between 0.025″ and 2mm. Depending on the size, pressure ratings range from 70 Mpa to 100 Mpa.

What surface finish can I expect on the coiled tubing?

The coiled tubes feature a bright annealed surface. They are polished soft both inside and out, thoroughly cleaned, and passivated, making them ready for immediate application.

What is the standard continuous length of a tube coil?

We can produce single coils starting from at least 8,000 to 10,000 feet (approximately 2,400 to 3,000 meters) depending on the tube size. Customized lengths are also available to meet specific application requirements.

What applications are these stainless steel coiled control lines used for?

They are commonly utilized in high-pressure instrumentation, medical acupuncture, coal exploration, thermostats, expansion valves (such as Danfoss valves), beer machine tubing, and drinking water delivery systems.

What are the precise size tolerances and fluid compatibility of the capillary tubes?

For capillary lines with outer diameters between 0.3mm and 10mm, we maintain a tight tolerance range of 0.005mm to 0.01mm. These tubes are compatible with various fluids, including water, chemicals, gases, and oils.
