Stainless steels are high-alloy steels. These steels are available in four groups that include martensitic, austenitic, ferritic and precipitation-hardened steels. These groups are formed based on the crystalline structure of stainless steels.
Stainless steels contain larger amounts of chromium in comparison with other steels and thus have good corrosion resistance. Most of the stainless steels contain about 10% of chromium.
Grade 2205 stainless steel is a duplex stainless steel whose design enables combining improved resistance to pitting, high strength, stress corrosion, crevice corrosion and cracking. Grade 2205 stainless steel resists sulfide stress corrosion and chloride environments.
The following datasheet provides an overview of grade 2205 stainless steel.
The chemical composition of grade 2205 stainless steel is outlined in the following table.
| Element | Content (%) |
|---|---|
| Iron, Fe | 63.75-71.92 |
| Chromium, Cr | 21.0-23.0 |
| Nickel, Ni | 4.50-6.50 |
| Molybdenum, Mo | 2.50-3.50 |
| Manganese, Mn | 2.0 |
| Silicon, Si | 1.0 |
| Nitrogen, N | 0.080-0.20 |
| Carbon, C | 0.030 |
| Phosphorous, P | 0.030 |
| Sulfur, S | 0.020 |
The following table shows the physical properties of grade 2205 stainless steel.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.82 g/cm³ | 0.283 lb/in³ |
The mechanical properties of grade 2205 stainless steel are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength at break | 621 MPa | 90000 psi |
| Yield strength (@strain 0.200 %) | 448 MPa | 65000 psi |
| Elongation at break (in 50 mm) | 25.0 % | 25.0 % |
| Hardness, Brinell | 293 | 293 |
| Hardness, Rockwell c | 31.0 | 31.0 |
The thermal properties of grade 2205 stainless steel are given in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@20-100°C/68-212°F) | 13.7 µm/m°C | 7.60 µin/in°F |
Equivalent materials to grade 2205 stainless steel are:
| Region Group A | Region Group B |
|---|---|
| China | Taiwan |
| United States | Canada |
| UK | Bangladesh |
| Japan & South Korea | Mexico & South Africa |
| Iran | Saudi Arabia |
| Indonesia | Kuwait |
| Singapore | Brazil |
| Colombia | Netherlands |
| Germany | Tanzania |
| Malaysia | Israel |
| Nigeria | Spain |
| Iraq | Qatar |
| Turkey | Thailand |
| Oman | Australia |
| Venezuela | UAE |
The production facility has three production lines of stainless steel coiled tube and stainless steel pipe, with exporting experience for more than ten years. Bending, stretching, saw cutting, stamping, polishing, and other series of processing equipment are available. The stainless steel products are widely used in bathroom pendants, hanger accessories, hardware, condensation water heating equipment, hotel supplies, and more. Drawings or samples are sincerely welcomed for production.
Experience in exporting stainless steel tube products spans more than ten years.
Description: The production of stainless steel coil has a history of ten years, supported by two production lines that produce continuous welded pipe using complete equipment and leading technology. The introduction of world first-class bright annealing technology allows online stainless steel pipe softening treatment. In addition, tests for compression, flaring, bending, hardness (100%), stretch, and air tightness are standard. Reliable quality is provided at reasonable prices, with exports reaching globally.
Experience in exporting stainless steel tube products spans more than ten years.
| Schedule 9.52mm Type 2205 Stainless Steel Pipe | Schedule 9.52*1.24mm 2205 Stainless Steel coiled Pipe |
| ASTM 5564 1/8” 2205 Seamless Tubing coiled tubing | Polished alloy2205 Stainless Steel coiled Tubing |
| 2205 Stainless Steel Threaded Pipe | SUS alloy2205 Stainless Steel Rectangular Tube |
| JIS SUS 2205 Seamless Coiled Tubes | alloy2205 SS Round Tube suppliers |
| SS 304 Welded Tubes for oil and Gas | AMTM alloy2205 Seamless Tube suppliers |
| ASTM A312 TP304 Coiled Tubing | Stainless Steel Inox alloy2205 Capillary Tubing |
| ASTM A312 Gr TP 2205 Aerospace tubes | AMS 5566 alloy2205 High Pressure Tube |
| SA213 TP 2205 Sighting Tube | Typealloy2205 Stainless Steel Polished Pipes |
| ASTM A312 TP2205 Elliptical and Oval Tubes | AMS 5567 alloy2205 seamless steel coiled Tube |
| ASTM A213 TP2205 Condenser Tube | AMS 5563 alloy2205 1/4” *0089”Seamless seamless steel tubes |
| ASTM A269 TP2205 straight tube boiler | AMS 5563 alloy2205 Welded furnace tube |
| ASTM A249 TP2205 Mirror Tube | AMS 5564 alloy2205 1/8” Welded Tubing, High-Pressure Hydraulic |
| UNS 2205 Pitot Tube stockist | Stainless Steel alloy2205 Seamless Round Tubing |
| ASTM A358 alloy2205 Polished Tubing | alloy2205 Stainless Steel Ornamental Tube |
| Stainless Steel alloy2205 Exhaust Pipe | alloy2205 Stainless Steel Spiral Pipe |
| ASME SA213 alloy2205 Perforated Tube | WERKSTOFF NR. 1.4301 Flexible Tube |
| SA 688 alloy2205 Finned Tube | SS alloy2205 seamless steel coiled Tube |
| Din 1.4301 AISI alloy2205 Perforated Exhaust Tube | Stainless Steel alloy2205 Hypodermic Tubing |
| Din W.-Nr. 1.4301 Aisi alloy2205 Corrugated Tube | SS alloy2205 Honed Tube |
| Material 1.4301 Aisi alloy2205 Slotted Handrail Tube | SS alloy2205 Thin Wall Tube |
| ASTM alloy2205 3/8”*0.035” stainless steel coiled tube | alloy2205 Stainless Steel Threaded Pipe |
| Stainless Steel alloy2205 Ornamental Pipe | Stainless Steel alloy2205 Fin Tube / Finned Tube |
| Salloy2205 Stainless Steel U Shaped Tube | alloy2205 Stainless Steel Square Tube Mirror Finish |
| Din 1.4301 Material Vacuum Tube | ASTM alloy2205 6.35*1.24 stainless steel coiled tubing |
| alloy2205 Stainless Steel Rectangular Pipe | alloy2205 Stainless Steel Hypodermic Tubing for Medical Needle |
| Ultra-High Purity Electropolished Stainless Steel alloy2205 Tube | Thin Wall Stainless Steel alloy2205 Tube |
| Din 1.4301 alloy2205 Stainless Steel Annealed Tubing | alloy2205 Stainless Steel Coil Tubing Heat Exchanger |
| SAE J405 Uns alloy2205 Thin Wall Tubing | alloy2205 Stainless Steel Metric Tubing |
| alloy2205 Stainless Steel Seamless Square Tubing | Large Diameter alloy2205 Stainless Steel Tube |
| alloy2205 Stainless Steel Lined Pipe | Corrugated alloy2205 Stainless Steel Tube for Gas and oil |
| ASTM A269 alloy2205 stainless steel coiled tubing | alloy2205 Stainless Steel Instrumentation Tubing |
| alloy2205 9.52*1.24MM Coiled Tubing | alloy2205 Stainless Steel Square Tubing |
| High-pressure alloy2205 Stainless Steel Water Pipe | Stainless Steel alloy2205 Hexagonal Pipe |
| Js alloy2205 stainless Steel Coil Tubing | Stainless Steel alloy2205 Boiler Tube |
