ASTM A269 alloy 2205 stainless steel coil tubing suppliers
Introduction
stainless steel coil tube | stainless steel tube coil | stainless steel coil tubing | stainless steel coil pipe | stainless steel coil tube suppliers | stainless steel coil tube manufacturers | stainless steel pipe coil
Stainless steels are high-alloy steels. These steels are available in four groups that include martensitic, austenitic, ferritic and precipitation-hardened steels. These groups are formed based on the crystalline structure of stainless steels.
Stainless steels contain larger amounts of chromium in comparison with other steels and thus have good corrosion resistance. Most of the stainless steels contain about 10% of chromium.
Grade 2205 stainless steel is a duplex stainless steel whose design enables combining improved resistance to pitting, high strength, stress corrosion, crevice corrosion and cracking. Grade 2205 stainless steel resists sulfide stress corrosion and chloride environments.
★ alloy 2205 Stainless steel coiled tubing /coiled tubes Specification:
- Production standards: ASTM A269/A249, standard
- Commonly used stainless steel material TP304, TP316, 201, 202, 310S, 321, 2205, 825, 625
- Trade Name: SS304 Coiled Tubes, SS316 Coiled Tubes, Duplex Coiled Tubes, Monel 400 Coiled Tubes, Hastelloy Coiled Tubes, Inconel coiled Tubes, 904L Coiled Tubes, Seamless Coiled Tubes, Welded Coiled Tubing
- Size range: diameter 3MM-25.4MM
- Wall thicknesses: 0.3MM-2.0MM
- General delivery pipe status: half hard / soft bright annealing
- The tolerance range: diameter: + 0.1mm, wall thickness: + 10%, length: -0/+6mm
- Annual output: 600 tons
- Coil inner hole size: 500MM-1500MM (can be adjusted according to customer requirements)
- Coil height: 200MM-400MM (can be adjusted according to customer requirements)
- General delivery length: 200 m -1000 M
- Length: 300-2000M or more than 2000M
- Main application and field of use: refrigeration equipment, evaporator, gas liquid delivery, condenser, beverage machine.
The following datasheet provides an overview of grade 2205 stainless steel.
Chemical Composition
The chemical composition of grade 2205 stainless steel is outlined in the following table.
| Element |
Content (%) |
| Iron, Fe |
63.75-71.92 |
| Chromium, Cr |
21.0-23.0 |
| Nickel, Ni |
4.50-6.50 |
| Molybdenum, Mo |
2.50-3.50 |
| Manganese, Mn |
2.0 |
| Silicon, Si |
1.0 |
| Nitrogen, N |
0.080-0.20 |
| Carbon, C |
0.030 |
| Phosphorous, P |
0.030 |
| Sulfur, S |
0.020 |
Physical Properties
The following table shows the physical properties of grade 2205 stainless steel.
| Properties |
Metric |
Imperial |
| Density |
7.82 g/cm³ |
0.283 lb/in³ |
Mechanical Properties
The mechanical properties of grade 2205 stainless steel are displayed in the following table.
| Properties |
Metric |
Imperial |
| Tensile strength at break |
621 MPa |
90000 psi |
| Yield strength (@strain 0.200 %) |
448 MPa |
65000 psi |
| Elongation at break (in 50 mm) |
25.0 % |
25.0 % |
| Hardness, Brinell |
293 |
293 |
| Hardness, Rockwell c |
31.0 |
31.0 |
Thermal Properties
The thermal properties of grade 2205 stainless steel are given in the following table.
| Properties |
Metric |
Imperial |
| Thermal expansion co-efficient (@20-100°C/68-212°F) |
13.7 µm/m°C |
7.60 µin/in°F |
Other Designations
Equivalent materials to grade 2205 stainless steel are:
- ASTM A182 Grade F51
- ASTM A240
- ASTM A789
- ASTM A790
- DIN 1.4462
★ Commonly Size of stainless steel coiled tube: we can product them as your request.
| ITEM |
Grade |
Size (MM) |
Pressure (Mpa) |
Length (M) |
| 1 |
316L、304L、304 alloy 625 825 2205 2507 |
1/8″×0.025″ |
3200 |
500-2000 |
| 2 |
316L、304L、304 alloy 625 825 2205 2507 |
1/8″×0.035″ |
3200 |
500-2000 |
| 3 |
316L、304L、304 alloy 625 825 2205 2507 |
1/4″×0.035″ |
2000 |
500-2000 |
| 4 |
316L、304L、304 alloy 625 825 2205 2507 |
1/4″×0.049″ |
2000 |
500-2000 |
| 5 |
316L、304L、304 alloy 625 825 2205 2507 |
3/8″×0.035″ |
1500 |
500-2000 |
| 6 |
316L、304L、304 alloy 625 825 2205 2507 |
3/8″×0.049″ |
1500 |
500-2000 |
| 7 |
316L、304L、304 alloy 625 825 2205 2507 |
1/2″×0.049″ |
1000 |
500-2000 |
| 8 |
316L、304L、304 alloy 625 825 2205 2507 |
1/2″×0.065″ |
1000 |
500-2000 |
| 9 |
316L、304L、304 alloy 625 825 2205 2507 |
φ3mm×0.7mm |
3200 |
500-2000 |
| 10 |
316L、304L、304 alloy 625 825 2205 2507 |
φ3mm×0.9mm |
3200 |
500-2000 |
| 11 |
316L、304L、304 alloy 625 825 2205 2507 |
φ4mm×0.9mm |
3000 |
500-2000 |
| 12 |
316L、304L、304 alloy 625 825 2205 2507 |
φ4mm×1.1mm |
3000 |
500-2000 |
| 13 |
316L、304L、304 alloy 625 825 2205 2507 |
φ6mm×0.9mm |
2000 |
500-2000 |
| 14 |
316L、304L、304 alloy 625 825 2205 2507 |
φ6mm×1.1mm |
2000 |
500-2000 |
| 15 |
316L、304L、304 alloy 625 825 2205 2507 |
φ8mm×1mm |
1800 |
500-2000 |
| 16 |
316L、304L、304 alloy 625 825 2205 2507 |
φ8mm×1.2mm |
1800 |
500-2000 |
| 17 |
316L、304L、304 alloy 625 825 2205 2507 |
φ10mm×1mm |
1500 |
500-2000 |
| 18 |
316L、304L、304 alloy 625 825 2205 2507 |
φ10mm×1.2mm |
1500 |
500-2000 |
| 19 |
316L、304L、304 alloy 625 825 2205 2507 |
φ10mm×2mm |
500 |
500-2000 |
| 20 |
316L、304L、304 alloy 625 825 2205 2507 |
φ12mm×1.5mm |
500 |
500-2000 |
▼ Stainless steel coiled tube coiled tubing stock range
| Item |
W.T / O.D (mm) |
3.0-4.0 |
4.01-6.00 |
6.01-8.00 |
8.01-10.0 |
10.01-12.7 |
12.71-19.05 |
19.05-25.4 |
| Stainless Steel Coiled Tubes/ Coil Tubing |
0.30-0.40 |
√ |
√ |
√ |
|
|
|
|
| 0.41-0.50 |
√ |
√ |
√ |
√ |
|
|
|
| 0.51-0.60 |
√ |
√ |
√ |
√ |
√ |
|
|
| 0.61-0.70 |
√ |
√ |
√ |
√ |
√ |
√ |
|
| 0.71-1.00 |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
| 1.01-1.20 |
|
√ |
√ |
√ |
√ |
√ |
√ |
| 1.21-1.50 |
|
|
|
√ |
√ |
√ |
√ |
| Stainless Steel Coiled Tubes/ Coil Tubing |
1.51-2.0 |
|
|
|
|
√ |
√ |
√ |
▼ Looking for a reliable stainless steel coiled tubing /coil tubes dealer distributor in below countries:
China
Taiwan
United States
Canada
UK
Bangladesh
Japan
South Korea
Mexico
South Africa
Iran
Saudi Arabia
Indonesia
Kuwait
Singapore
Brazil
Colombia
Netherlands
Germany
Tanzania
Malaysia
Israel
Nigeria
Spain
Iraq
Qatar
Turkey
Thailand
Oman
Australia
Venezuela
UAE
▼ Stainless steel coiled tubing /coiled tubes material grade comparison:
| U.S.A. (AISI) |
GERMANY (DIN 17006) |
GERMANY (W.N. 17007) |
FRANCE (AFNOR) |
JAPAN (JIS) |
ITALY (UNI) |
SWEDEN (SIS) |
U.K. (BSI) |
E.U. (EURONORM) |
RUSSIA |
| 201 |
|
|
|
SUS 201 |
|
|
|
|
|
| 301 |
X 12 CrNi 17 7 |
1.4310 |
Z 12 CN 17-07 |
SUS 301 |
X 12 CrNi 1707 |
23 31 |
301S21 |
X 12 CrNi 17 7 |
|
| 302 |
X 5 CrNi 18 7 |
1.4319 |
Z 10 CN 18-09 |
SUS 302 |
X 10 CrNi 1809 |
23 31 |
302S25 |
X 10 CrNi 18 9 |
12KH18N9 |
| 303 |
X 10 CrNiS 18 9 |
1.4305 |
Z 10 CNF 18-09 |
SUS 303 |
X 10 CrNiS 1809 |
23 46 |
303S21 |
X 10 CrNiS 18 9 |
|
| 303 Se |
|
|
Z 10 CNF 18-09 |
SUS 303 Se |
X 10 CrNiS 1809 |
|
303S41 |
|
12KH18N10E |
| 304 |
X 5 CrNi 18 10 / X 5 CrNi 18 12 |
1.4301 / 1.4303 |
Z 6 CN 18-09 |
SUS 304 |
X 5 CrNi 1810 |
23 32 |
304S15 / 304S16 |
X 6 CrNi 18 10 / X 6 CrNi 19-10 |
08KH18N10 / 06KH18N11 |
| 304 N |
|
|
|
SUS 304N1 |
X 5 CrNiN 1810 |
|
|
|
|
| 304 H |
|
|
|
SUS F 304H |
X 8 CrNi 1910 |
|
|
|
|
| 304 L |
X 2 CrNi 18 11 |
1.4306 |
Z 2 CN 18-10 |
SUS 304L |
X 2 CrNi 1911 |
23 52 |
304S11 |
X 3 CrNi 18 10 / X 2 CrNi 19-10 |
03KH18N11 |
| 304LN |
X 2 CrNiN 18 10 |
1.4311 |
Z 2 CN 18-10-Az |
SUS 304LN |
X 2 CrNiN 1811 |
23 71 |
|
|
|
| 305 |
|
|
Z 8 CN 18-12 |
SUS 305 |
X 8 CrNi 1812 |
23 33 |
305S19 |
X 8 CrNi 18 12 / X 8 CrNi 18-12 |
|
| XM7 |
|
|
Z 6 CNU 18-10 |
SUS XM7 |
|
|
|
X 6 CrNiCu 18 10 4 Kd |
|
| 309 |
X 15 CrNiS 20 12 |
1.4828 |
Z 15 CN 24-13 |
SUH 309 |
X 16 CrNi 2314 |
|
309S24 |
X 15 CrNi 23 13 |
|
| 309 S |
|
|
|
SUS 309S |
X 6 CrNi 2314 |
|
|
X 6 CrNi 22 13 |
|
| 310 |
X 12 CrNi 25 21 |
1.4845 |
|
SUH 310 |
X 22 CrNi 2520 |
|
310S24 |
|
20KH23N18 |
| 310 S |
X 12 CrNi 25 20 |
1.4842 |
Z 12 CN 25-20 |
SUS 310S |
X 5 CrNi 2520 |
23 61 |
|
X 6 CrNi 25 20 |
10KH23N18 |
| 314 |
X 15 CrNiSi 25 20 |
1.4841 |
Z 12 CNS 25-20 |
|
X 16 CrNiSi 2520 |
|
|
X 15 CrNiSi 25 20 |
20KH25N20S2 |
| 316 |
X 5 CrNiMo 17 12 2 |
1.4401 |
Z 6 CND 17-11 |
SUS 316 |
X 5 CrNiMo 1712 |
23 47 |
316S31 |
X 6 CrNiMo 17 12 2 / X 6 CrNiMo 17-12-03 |
|
| 316 (H) |
X 5 CrNiMo 17 13 3 |
1.4436 |
Z 6 CND 17-12 |
SUS 316 |
X 5 CrNiMo 1713 |
23 43 |
316S33 |
X 6 CrNiMo 17 13 3 |
|
| 316 F |
X 12 CrNiMoS 18 11 |
1.4427 |
|
|
|
|
|
|
|
| 316 N |
|
|
|
SUS 316N |
|
|
|
|
|
| 316 H |
|
|
|
SUS F 316H |
X 8 CrNiMo 1712 / X 8 CrNiMo 1713 |
|
|
X 5 CrNiMo 17-12 / X 6 CrNiMo 17-12-03 |
|
| 316 L |
X 2 CrNiMo 17 13 2 |
1.4404 |
Z 2 CND 17-12 |
SUS 316L |
X 2 CrNiMo 1712 |
23 48 |
316S11 |
X 3 CrNiMo 17 12 2 / X 2 CrNiMo 17-12-03 |
03KH17N14M2 |
| 316LN |
X 2 CrNiMoN 17 12 2 |
1.4406 |
Z 2 CND 17-12-Az |
SUS 316LN |
X 2 CrNiMoN 1712 |
|
|
|
|
| 316 L (3) |
X 2 CrNiMo 18 14 3 |
1.4435 |
Z 2 CND 17-13 |
|
X 2 CrNiMo 1713 |
23 53 |
316S13 |
X 3 CrNiMo 17 13 3 |
03KH16N15M3 |
| 316LN(3) |
X 2 CrNiMoN 17 13 3 |
1.4429 |
Z 2 CND 17-13-Az |
|
X 2 CrNiMoN 1713 |
23 75 |
|
|
|
| 316Ti |
X 6 CrNiMoTi 17 12 2 |
1.4571 |
Z 6 CNDT 17-12 |
|
X 6 CrNiMoTi 1712 |
23 50 |
320S31 |
X 6 CrNiMoTi 17 12 2 / X 6 CrNiMoTi 17-12-03 |
08KH17N13M2T / 10KH17N13M2T |
| 316Ti(3) |
X 10 CrNiMoTi 18 12 |
1.4573 |
|
|
X 6 CrNiMoTi 1713 |
|
320S33 |
X 6 CrNiMoTi 17 13 3 |
|
| 316Nb |
X 6 CrNiMoNb 17 12 2 |
1.4580 |
Z 6 CNDNb 17-12 |
|
X 6 CrNiMoNb 1712 |
|
|
X 6 CrNiMoNb 17 12 2 |
08KH16N13M2B |
| 316Nb(3) |
X 10 CrNiMoNb 18 12 |
1.4583 |
|
|
X 6 CrNiMoNb 1713 |
|
|
X 6 CrNiMoNb 17 13 3 |
09KH16N15M3B |
| 317 |
|
|
|
SUS 317 |
X 5 CrNiMo 1815 |
23 66 |
317S16 |
|
|
| 317 L |
X 2 CrNiMo 18 16 4 |
1.4438 |
Z 2 CND 19-15 |
SUS 317L |
X 2 CrNiMo 1815 / X 2 CrNiMo 1816 |
23 67 |
317S12 |
X 3 CrNiMo 18 16 4 |
|
| 330 |
X 12 NiCrSi 36 16 |
1.4864 |
Z 12NCS 35-16 |
SUH 330 |
|
|
|
|
|
| 321 |
X 6 CrNiTi 18 10 / X 12 CrNiTi 18 9 |
1.4541 / 1.4878 |
Z 6 CNT 18-10 |
SUS 321 |
X 6 CrNiTi 1811 |
23 37 |
321S31 |
X 6 CrNiTi 18 10 / X 6 CrNiTi 18-11 |
08KH18N10T |
| 321 H |
|
|
|
SUS 321H |
X 8 CrNiTi 1811 |
|
321S20 |
|
12KH18N10T |
| 329 |
X 8 CrNiMo 27 5 |
1.4460 |
|
SUS 329J1 |
|
23 24 |
|
|
|
| 347 |
X 6 CrNiNb 18 10 |
1.4550 |
Z 6 CNNb 18-10 |
SUS 347 |
X 6 CrNiNb 1811 |
23 38 |
347S31 |
X 6 CrNiNb 18 10 / X 6 CrNiNb 18-11 |
08KH18N12B |
| 347 H |
|
|
|
SUS F 347H |
X 8 CrNiNb 1811 |
|
|
|
|
| 904L |
|
1.4939 |
Z 12 CNDV 12-02 |
|
|
|
|
|
|
| UNS31803 |
X 2 CrNiMoN 22 5 |
1.4462 |
|
|
|
|
|
|
|
| UNS32760 |
X 3 CrNiMoN 25 7 |
1.4501 |
Z 3 CND 25-06Az |
|
|
|
|
|
|
| 403 |
X 6 Cr 13 / X 10 Cr 13 / X 15 Cr 13 |
1.4000 / 1.4006 / 1.4024 |
Z 12 C 13 |
SUS 403 |
X 12 Cr 13 |
23 02 |
403S17 |
X 10 Cr 13 / X 12 Cr 13 / X 6 Cr 13 |
12Kh13 |
| 405 |
X 6 CrAl 13 |
1.4002 |
Z 6 CA 13 |
SUS 405 |
X 6 CrAl 13 |
|
405S17 |
X 6 CrAl 13 |
|
| 405 (7) |
X 10 CrAl 7 |
1.4713 |
Z 8 CA 7 |
|
|
|
|
X 10 CrAl 7 |
|
| 405 (12) |
X 10 CrAl 13 |
1.4724 |
|
|
X 10 CrAl 12 |
|
|
|
10Kh13SYu |
| 405 (18) |
X 10 CrAl 18 |
1.4742 |
|
|
|
|
|
X 10 CrSiAl 18 |
15Kh18SYu |
| 409 |
X 6 CrTi 12 |
1.4512 |
Z 6 CT 12 |
SUH 409 |
X 6 CrTi 12 / X 2 CrTi 12 |
|
409S19 |
X 5 CrTi 12 |
|
| 410 |
X 6 Cr 13 / X 10 Cr 13 / X 15 Cr 13 |
1.4000 / 1.4006 / 1.4024 |
Z 10 C 13 / Z 12 C 13 |
SUS 410 |
X 12 Cr 13 |
23 02 |
410S21 |
X 12 Cr 13 |
12Kh13 |
| 410 S |
X 6 Cr 13 |
1.4000 |
Z 6 C 13 |
SUS 410S |
X 6 Cr 13 |
23 01 |
403S17 |
X 6 Cr 13 |
08Kh13 |
▼ Our advantages:
We are a stainless steel coiled tube/pipe manufacturer.
We can control the quality of pipe by ourselves.
The length of the pipes is more than 3500M/Coil.
▼ Description:
There are three production lines of stainless steel coiled tube and stainless steel pipe, with exporting experience for more than ten years. Processing equipment includes bending, stretching, saw cutting, stamping, polishing, and more. These stainless steel products are widely used in bathroom pendants, hanger accessories, hardware, condensation water heating equipment, hotel supplies, and other applications. We sincerely welcome domestic and foreign customers to provide drawings or samples.
We have experience to export stainless steel tube products for more than ten years.
Description: The production of stainless steel coil has ten years of history, with two production lines capable of producing continuous welded pipe, supported by complete equipment and leading technology. The production line utilizes world-first-class bright annealing technology for online stainless steel pipe softening treatment. In addition, compressed testing, flaring testing, bending testing, 100% hardness testing, stretch testing, and air tightness testing are performed. The pricing is reasonable and the quality is reliable. Currently, 80% of our coil is exported to global markets.
▼ Stainless steel coiled tubes /stainless steel coiled tubing other Grades:
- Stainless Steel 304 Coiled Tubes/ Coil Tubing
- Stainless Steel 304L Coiled Tubes/ Coil Tubing
- Stainless Steel 304H Coiled Tubes/ Coil Tubing
- Stainless Steel 316 Coiled Tubes/ Coil Tubing
- Stainless Steel 316L Coiled Tubes/ Coil Tubing
- Stainless Steel 316H Coiled Tubes/ Coil Tubing
- Stainless Steel 317L Coiled Tubes/ Coil Tubing
- Stainless Steel 321 Coiled Tubes/ Coil Tubing
- Stainless Steel 347 Coiled Tubes/ Coil Tubing
- Stainless Steel 410 Coiled Tubes/ Coil Tubing
- Stainless Steel 904L Coiled Tubes/ Coil Tubing
- Stainless Steel 310S Coiled Tubes/ Coil Tubing
- Stainless Steel 310 Coiled Tubes/ Coil Tubing
- Stainless Steel 310H Coiled Tubes/ Coil Tubing
- Stainless Steel 316Ti Coiled Tubes/ Coil Tubing
- Stainless Steel 321H Coiled Tubes/ Coil Tubing
- Stainless Steel 347 Coiled Tubes/ Coil Tubing
- Stainless Steel 347H Coiled Tubes/ Coil Tubing
We have experience to export stainless steel tube products for more than ten years.
▼ Seamless coiled tubing is a no. 1 choice in most of the critical applications as there is no risk of impurities that are often associated with welded coiled tubing.
- Made available in custom lengths
- Improved system safety and reliability
- Greater corrosion resistance
- Reduces the use of fittings, preventing the possibilities of leaks and other long-term failures
- Reduced installation costs – installation involves less time and efforts
▼ STAINLESS STEEL COILED TUBES /COILED TUBING APPLICATION:
- Food & Beverage Industry
- Petrochemical
- CNG Piping Jobs
- Boilers
- Desalination Plants
- Geothermal Plants
- Heat Exchangers
- Instrumentation Jobs
- Mechanical Jobs
- Oil and Gas Equipments and Piping Works
▼ Widest range of Stainless Steel 304 Seamless, Welded Pipes & Tubes in shandong China:
| Schedule 9.52mm Type 2205 Stainless Steel Pipe |
Schedule 9.52*1.24mm 2205 Stainless Steel coiled Pipe |
| ASTM 5564 1/8” 2205 Seamless Tubing coiled tubing |
Polished alloy2205 Stainless Steel coiled Tubing |
| 2205 Stainless Steel Threaded Pipe |
SUS alloy2205 Stainless Steel Rectangular Tube |
| JIS SUS 2205 Seamless Coiled Tubes |
alloy2205 SS Round Tube suppliers |
| SS 304 Welded Tubes for oil and Gas |
AMTM alloy2205 Seamless Tube suppliers |
| ASTM A312 TP304 Coiled Tubing |
Stainless Steel Inox alloy2205 Capillary Tubing |
| ASTM A312 Gr TP 2205 Aerospace tubes |
AMS 5566 alloy2205 High Pressure Tube |
| SA213 TP 2205 Sighting Tube |
Typealloy2205 Stainless Steel Polished Pipes |
| ASTM A312 TP2205 Elliptical and Oval Tubes |
AMS 5567 alloy2205 seamless steel coiled Tube |
| ASTM A213 TP2205 Condenser Tube |
AMS 5563 alloy2205 1/4” *0089”Seamless seamless steel tubes |
| ASTM A269 TP2205 straight tube boiler |
AMS 5563 alloy2205 Welded furnace tube |
| ASTM A249 TP2205 Mirror Tube |
AMS 5564 alloy2205 1/8” Welded Tubing, High-Pressure Hydraulic |
| UNS 2205 Pitot Tube stockist |
Stainless Steel alloy2205 Seamless Round Tubing |
| ASTM A358 alloy2205 Polished Tubing |
alloy2205 Stainless Steel Ornamental Tube |
| Stainless Steel alloy2205 Exhaust Pipe |
alloy2205 Stainless Steel Spiral Pipe |
| ASME SA213 alloy2205 Perforated Tube |
WERKSTOFF NR. 1.4301 Flexible Tube |
| SA 688 alloy2205 Finned Tube |
SS alloy2205 seamless steel coiled Tube |
| Din 1.4301 AISI alloy2205 Perforated Exhaust Tube |
Stainless Steel alloy2205 Hypodermic Tubing |
| Din W.-Nr. 1.4301 Aisi alloy2205 Corrugated Tube |
SS alloy2205 Honed Tube |
| Material 1.4301 Aisi alloy2205 Slotted Handrail Tube |
SS alloy2205 Thin Wall Tube |
| ASTM alloy2205 3/8”*0.035” stainless steel coiled tube |
alloy2205 Stainless Steel Threaded Pipe |
| Stainless Steel alloy2205 Ornamental Pipe |
Stainless Steel alloy2205 Fin Tube / Finned Tube |
| Salloy2205 Stainless Steel U Shaped Tube |
alloy2205 Stainless Steel Square Tube Mirror Finish |
| Din 1.4301 Material Vacuum Tube |
ASTM alloy2205 6.35*1.24 stainless steel coiled tubing |
| alloy2205 Stainless Steel Rectangular Pipe |
alloy2205 Stainless Steel Hypodermic Tubing for Medical Needle |
| Ultra-High Purity Electropolished Stainless Steel alloy2205 Tube |
Thin Wall Stainless Steel alloy2205 Tube |
| Din 1.4301 alloy2205 Stainless Steel Annealed Tubing |
alloy2205 Stainless Steel Coil Tubing Heat Exchanger |
| SAE J405 Uns alloy2205 Thin Wall Tubing |
alloy2205 Stainless Steel Metric Tubing |
| alloy2205 Stainless Steel Seamless Square Tubing |
Large Diameter alloy2205 Stainless Steel Tube |
| alloy2205 Stainless Steel Lined Pipe |
Corrugated alloy2205 Stainless Steel Tube for Gas and oil |
| ASTM A269 alloy2205 stainless steel coiled tubing |
alloy2205 Stainless Steel Instrumentation Tubing |
| alloy2205 9.52*1.24MM Coiled Tubing |
alloy2205 Stainless Steel Square Tubing |
| High-pressure alloy2205 Stainless Steel Water Pipe |
Stainless Steel alloy2205 Hexagonal Pipe |
| Jis alloy2205 stainless Steel Coil Tubing |
Stainless Steel alloy2205 Boiler Tube |
Frequently Asked Questions (FAQ)
What are the primary benefits of Grade 2205 duplex stainless steel?
Grade 2205 is a duplex stainless steel designed to offer superior strength and enhanced resistance to pitting, stress corrosion cracking, crevice corrosion, and sulfide/chloride environments compared to standard austenitic steels.
Why is seamless coiled tubing preferred over welded coiled tubing?
Seamless coiled tubing is the optimal choice for critical applications as it eliminates the risks of impurities associated with welded joints. It also reduces the need for fittings, decreases installation costs, and minimizes the potential for leaks.
What size and wall thickness ranges do you offer for coiled tubing?
Our standard size range features diameters from 3mm to 25.4mm, with wall thicknesses ranging between 0.3mm and 2.0mm. Custom sizes can also be produced to meet specific project demands.
In what lengths is the stainless steel coiled tubing delivered?
Our general delivery lengths span from 200m up to 1000m. Depending on requirements, we can provide seamless continuous pipes in single coil lengths exceeding 2000m to 3500m.
What standard grades of stainless steel coiled tubing are available?
We supply a comprehensive selection of material grades including TP304, TP316, 201, 202, 310S, 321, 2205 duplex, as well as high-performance alloys like 625, 825, and 904L.
What testing and quality control processes do the coiled pipes undergo?
To ensure maximum safety and performance, our coiled pipes undergo a series of rigorous evaluations including bright annealing, compressed and flaring tests, 100% hardness tests, stretch tests, and air tightness testing.
Sihe Steel
