Super alloys consist of a number of elements in a variety of combinations to achieve the desired result. They are further classified into three groups such as cobalt-based, nickel-based, and iron-based alloys.
Incoloy(r) alloy 825 is an austenitic nickel-iron-chromium alloy which is added with other alloying elements in order to improve its chemical corrosion resistant property. The following datasheet will provide more details about Incoloy(r) alloy 825.
ALLOY 825 stainless steel coil tubing pipe suppliers
| ITEM | Grade | Size (MM) | Pressure (Mpa) | Length (M) |
|---|---|---|---|---|
| 1 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/8″×0.025″ | 3200 | 500-2000 |
| 2 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/8″×0.035″ | 3200 | 500-2000 |
| 3 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/4″×0.035″ | 2000 | 500-2000 |
| 4 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/4″×0.049″ | 2000 | 500-2000 |
| 5 | 316L, 304L, 304 alloy 625 825 2205 2507 | 3/8″×0.035″ | 1500 | 500-2000 |
| 6 | 316L, 304L, 304 alloy 625 825 2205 2507 | 3/8″×0.049″ | 1500 | 500-2000 |
| 7 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/2″×0.049″ | 1000 | 500-2000 |
| 8 | 316L, 304L, 304 alloy 625 825 2205 2507 | 1/2″×0.065″ | 1000 | 500-2000 |
| 9 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ3mm×0.7mm | 3200 | 500-2000 |
| 10 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ3mm×0.9mm | 3200 | 500-2000 |
| 11 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ4mm×0.9mm | 3000 | 500-2000 |
| 12 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ4mm×1.1mm | 3000 | 500-2000 |
| 13 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ6mm×0.9mm | 2000 | 500-2000 |
| 14 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ6mm×1.1mm | 2000 | 500-2000 |
| 15 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ8mm×1mm | 1800 | 500-2000 |
| 16 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ8mm×1.2mm | 1800 | 500-2000 |
| 17 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ10mm×1mm | 1500 | 500-2000 |
| 18 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ10mm×1.2mm | 1500 | 500-2000 |
| 19 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ10mm×2mm | 500 | 500-2000 |
| 20 | 316L, 304L, 304 alloy 625 825 2205 2507 | φ12mm×1.5mm | 500 | 500-2000 |
| Item | W.T (mm) / O.D (mm) | 3.0-4.0 | 4.01-6.00 | 6.01-8.00 | 8.01-10.0 | 10.01-12.7 | 12.71-19.05 | 19.05-25.4 |
|---|---|---|---|---|---|---|---|---|
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.30-0.40 | √ | √ | √ | ||||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.41-0.50 | √ | √ | √ | √ | |||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.51-0.60 | √ | √ | √ | √ | √ | ||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.61-0.70 | √ | √ | √ | √ | √ | √ | |
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.71-1.00 | √ | √ | √ | √ | √ | √ | √ |
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.01-1.20 | √ | √ | √ | √ | √ | √ | |
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.21-1.50 | √ | √ | √ | √ | |||
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.51-2.0 | √ | √ | √ |
| Element | Content (%) |
|---|---|
| Nickel, Ni | 38-46 |
| Iron, Fe | 22 |
| Chromium, Cr | 19.5-23.5 |
| Molybdenum, Mo | 2.50-3.50 |
| Copper, Cu | 1.50-3.0 |
| Manganese, Mn | 1 |
| Titanium, Ti | 0.60-1.20 |
| Silicon, Si | 0.50 |
| Aluminum, Al | 0.20 |
| Carbon, C | 0.050 |
| Sulfur, S | 0.030 |
The physical properties of Incoloy(r) alloy 825 are given in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.14 g/cm³ | 0.294 lb/in³ |
| Melting point | 1385°C | 2525°F |
The mechanical properties of Incoloy(r) alloy 825 are highlighted in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength (annealed) | 690 MPa | 100000 psi |
| Yield strength (annealed) | 310 MPa | 45000 psi |
| Elongation at break (annealed prior to test) | 45% | 45% |
The thermal properties of Incoloy(r) alloy 825 are outlined in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (at 20-100°C/68-212°F) | 14 µm/m°C | 7.78 µin/in°F |
| Thermal conductivity | 11.1 W/mK | 77 BTU in/hr.ft².°F |
Are you looking for a reliable stainless steel coiled tubing / coil tubes dealer distributor in below countries:
| U.S.A. AISI | GERMANY DIN 17006 | GERMANY W.N. 17007 | FRANCE AFNOR | JAPAN JIS | ITALY UNI | SWEDEN SIS | U.K. BSI | E.U. EURONORM |
|---|---|---|---|---|---|---|---|---|
| 201 | SUS 201 | |||||||
| 301 | X 12 CrNi 17 7 | 1.4310 | Z 12 CN 17-07 | SUS 301 | X 12 CrNi 1707 | 23 31 | 301S21 | X 12 CrNi 17 7 |
| 302 | X 5 CrNi 18 7 | 1.4319 | Z 10 CN 18-09 | SUS 302 | X 10 CrNi 1809 | 23 31 | 302S25 | X 10 CrNi 18 9 |
| 303 | X 10 CrNiS 18 9 | 1.4305 | Z 10 CNF 18-09 | SUS 303 | X 10 CrNiS 1809 | 23 46 | 303S21 | X 10 CrNiS 18 9 |
| 303 Se | Z 10 CNF 18-09 | SUS 303 Se | X 10 CrNiS 1809 | 303S41 | ||||
| 304 | X 5 CrNi 18 10 | 1.4301 | Z 6 CN 18-09 | SUS 304 | X 5 CrNi 1810 | 23 32 | 304S15 | X 6 CrNi 18 10 |
| 304 N | SUS 304N1 | X 5 CrNiN 1810 | ||||||
| 304 H | SUS F 304H | X 8 CrNi 1910 | ||||||
| 304 L | X 2 CrNi 18 11 | 1.4306 | Z 2 CN 18-10 | SUS 304L | X 2 CrNi 1911 | 23 52 | 304S11 | X 3 CrNi 18 10 |
| 305 | Z 8 CN 18-12 | SUS 305 | X 8 CrNi 1812 | 23 33 | 305S19 | X 8 CrNi 18 12 | ||
| 309 | X 15 CrNiS 20 12 | 1.4828 | Z 15 CN 24-13 | SUH 309 | X 16 CrNi 2314 | 309S24 | X 15 CrNi 23 13 | |
| 309 S | SUS 309S | X 6 CrNi 2314 | X 6 CrNi 22 13 | |||||
| 310 | X 12 CrNi 25 21 | 1.4845 | SUH 310 | X 22 CrNi 2520 | 310S24 | |||
| 310 S | X 12 CrNi 25 20 | 1.4842 | Z 12 CN 25-20 | SUS 310S | X 5 CrNi 2520 | 23 61 | X 6 CrNi 25 20 | |
| 314 | X 15 CrNiSi 25 20 | 1.4841 | Z 12 CNS 25-20 | X 16 CrNiSi 2520 | X 15 CrNiSi 25 20 | |||
| 316 | X 5 CrNiMo 17 12 2 | 1.4401 | Z 6 CND 17-11 | SUS 316 | X 5 CrNiMo 1712 | 23 47 | 316S31 | X 6 CrNiMo 17 12 2 |
| 316 F | X 12 CrNiMoS 18 11 | 1.4427 | ||||||
| 316 N | SUS 316N | |||||||
| 316 H | SUS F 316H | X 8 CrNiMo 1712 | ||||||
| 316 L | X 2 CrNiMo 17 13 2 | 1.4404 | Z 2 CND 17-12 | SUS 316L | X 2 CrNiMo 1712 | 23 48 | 316S11 | X 3 CrNiMo 17 12 2 |
| 317 | SUS 317 | X 5 CrNiMo 1815 | 23 66 | 317S16 | ||||
| 317 L | X 2 CrNiMo 18 16 4 | 1.4438 | Z 2 CND 19-15 | SUS 317L | X 2 CrNiMo 1815 | 23 67 | 317S12 | X 3 CrNiMo 18 16 4 |
| 330 | X 12 NiCrSi 36 16 | 1.4864 | Z 12NCS 35-16 | SUH 330 | ||||
| 321 | X 6 CrNiTi 18 10 | 1.4541 | Z 6 CNT 18-10 | SUS 321 | X 6 CrNiTi 1811 | 23 37 | 321S31 | X 6 CrNiTi 18 10 |
| 321 H | SUS 321H | X 8 CrNiTi 1811 | 321S20 | |||||
| 329 | X 8 CrNiMo 27 5 | 1.4460 | SUS 329J1 | 23 24 | ||||
| 347 | X 6 CrNiNb 18 10 | 1.4550 | Z 6 CNNb 18-10 | SUS 347 | X 6 CrNiNb 1811 | 23 38 | 347S31 | X 6 CrNiNb 18 10 |
| 347 H | SUS F 347H | X 8 CrNiNb 1811 | ||||||
| 904L | 1.4939 | Z 12 CNDV 12-02 | ||||||
| UNS31803 | X 2 CrNiMoN 22 5 | 1.4462 | ||||||
| UNS32760 | X 3 CrNiMoN 25 7 | 1.4501 | Z 3 CND 25-06Az | |||||
| 403 | X 6 Cr 13 | 1.4000 | Z 12 C 13 | SUS 403 | X 12 Cr 13 | 23 02 | 403S17 | X 10 Cr 13 |
| 405 | X 6 CrAl 13 | 1.4002 | Z 6 CA 13 | SUS 405 | X 6 CrAl 13 | 405S17 | X 6 CrAl 13 | |
| 409 | X 6 CrTi 12 | 1.4512 | Z 6 CT 12 | SUH 409 | X 6 CrTi 12 | 409S19 | X 5 CrTi 12 | |
| 410 | X 6 Cr 13 | 1.4000 | Z 10 C 13 | SUS 410 | X 12 Cr 13 | 23 02 | 410S21 | X 12 Cr 13 |
| 410 S | X 6 Cr 13 | 1.4000 | Z 6 C 13 | SUS 410S | X 6 Cr 13 | 23 01 | 403S17 | X 6 Cr 13 |
Our production of stainless steel coil has a ten-year history, operating multiple production lines that produce continuous welded and seamless pipes. The facilities feature first-class bright annealing technology, enabling online stainless steel pipe softening treatment. Testing methods include compression, flaring, bending, hardness 100%, stretch, and air tightness tests, ensuring reliable quality. Our stainless steel products are widely used in bathroom pendants, hanger accessories, hardware, condensation water heating equipment, hotel supplies, and more.
Seamless coiled tubing is the preferred choice in critical applications as there is no risk of impurities often associated with welded coiled tubing.
| Product Type | Product Specification |
|---|---|
| Schedule 9.52mm Type alloy 825 Stainless Steel Pipe | Schedule 9.52*1.24mm alloy 825 Stainless Steel coiled Pipe |
| ASTM 5564 1/8” alloy 825 Seamless Tubing coiled tubing | Polished alloy 825 Stainless Steel coiled Tubing |
| alloy 825 Stainless Steel Threaded Pipe | SUS alloy 825 Stainless Steel Rectangular Tube |
| JIS SUS alloy 825 Seamless Coiled Tubes | alloy 825 SS Round Tube suppliers |
| alloy 825 Welded Tubes for oil and Gas | AMTM alloy 825 Seamless Tube suppliers |
| ASTM A312 alloy 825 Coiled Tubing | Stainless Steel Inox alloy 825 Capillary Tubing |
| ASTM A312 Gr alloy 825 Aerospace tubes | AMS 5566 alloy 825 High Pressure Tube |
| SA213 alloy 825 Sighting Tube | alloy 825 Stainless Steel Polished Pipes |
| ASTM A312 alloy 825 Elliptical and Oval Tubes | AMS 5567 alloy 825 seamless steel coiled Tube |
| ASTM A213 alloy 825 Condenser Tube | AMS 5563 alloy 825 1/4” *0.089” Seamless steel tubes |
| ASTM A269 alloy 825 straight tube boiler | AMS 5563 alloy 825 Welded furnace tube |
| ASTM A249 alloy 825 Mirror Tube | AMS 5564 alloy 825 1/8” Welded Tubing, High-Pressure Hydraulic |
| UNS alloy 825 Pitot Tube stockist | Stainless Steel alloy 825 Seamless Round Tubing |
| ASTM A358 alloy825 Polished Tubing | alloy 825 Stainless Steel Ornamental Tube |
| Stainless Steel alloy825 Exhaust Pipe | alloy 825 Stainless Steel Spiral Pipe |
| ASME SA213 alloy825 Perforated Tube | WERKSTOFF NR. 1.4301 alloy 825 Flexible Tube |
| SA 688 alloy825 Finned Tube | SS alloy825 seamless steel coiled Tube |
| Din 1.4301 AISI alloy825 Perforated Exhaust Tube | Stainless Steel alloy825 Hypodermic Tubing |
| Din W.-Nr. 1.4301 Aisi alloy825 Corrugated Tube | SS alloy825 Honed Tube |
| Material 1.4301 Aisi alloy825 Slotted Handrail Tube | SS alloy825 Thin Wall Tube |
| ASTM alloy825 3/8”*0.035” stainless steel coiled tube | Alloy825 Stainless Steel Threaded Pipe |
| Stainless Steel alloy825 Ornamental Pipe | Stainless Steel alloy825 Fin Tube / Finned Tube |
| Salloy 825 Stainless Steel U Shaped Tube | Alloy825 Stainless Steel Square Tube Mirror Finish |
| Din 1.4301 825 Material Vacuum Tube | ASTM alloy825 6.35*1.24 stainless steel coiled tubing |
| Alloy825 Stainless Steel Rectangular Pipe | Alloy825 Stainless Steel Hypodermic Tubing for Medical Needle |
| Ultra-High Purity Electropolished Stainless Steel alloy825 Tube | Thin Wall Stainless Steel alloy825 Tube |
| Din 1.4301 alloy825 Stainless Steel Annealed Tubing | Alloy825 Stainless Steel Coil Tubing Heat Exchanger |
| SAE J405 Uns alloy825 Thin Wall Tubing | Alloy825 Stainless Steel Metric Tubing |
| Alloy825 Stainless Steel Seamless Square Tubing | Large Diameter alloy825 Stainless Steel Tube |
| Alloy825 Stainless Steel Lined Pipe | Corrugated alloy825 Stainless Steel Tube for Gas and oil |
| ASTM A269 alloy825 stainless steel coiled tubing | Alloy825 Stainless Steel Instrumentation Tubing |
| Alloy825 9.52*1.24MM Coiled Tubing | Alloy825 Stainless Steel Square Tubing |
| High-pressure alloy825 Stainless Steel Water Pipe | Stainless Steel alloy825 Hexagonal Pipe |
| Jis alloy825 stainless Steel Coil Tubing | Stainless Steel alloy825 Boiler Tube |
