304 Stainless Steel Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
Stainless Steel 304 Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
Stainless Steel 304 Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304 | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Electric Properties
| Properties | Conditions | ||
|---|---|---|---|
| T (°C) | Treatment | ||
| Electric Resistivity (10-9W-m) | 720 | 25 | |
Stainless Steel 304 Equivalent Equivalent Grades for 304 Stainless Steel
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | GOST | ||
|---|---|---|---|---|---|---|---|---|
| BS | En | No | Name | |||||
| SS 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 | 08Х18Н10 |
stainless steel coil tube | stainless steel tube coil | stainless steel coil tubing | stainless steel coil pipe | stainless steel coil tube suppliers | stainless steel coil tube manufacturers | stainless steel pipe coil
316 STAINLESS STEEL COIL TUBING, STAINLESS STEEL 316L COIL TUBE DEALER, STAINLESS STEEL 201 COIL TUBES SUPPLIER, SS COIL TUBE EXPORTER, STAINLESS STEEL WELDED COIL TUBE, STEEL COIL TUBING
We are a privately owned Supplier of Stainless Steel Coil Tube and stainless steel welded pipe manufactured in accordance with national and international standards. We are also stockists and distributors of Stainless Steel Seamless Coil Tube and Stainless Steel Welded Coil Tube. We have earned the status of a preferred Stainless Steel Coil Tube manufacturer. Our Stainless Steel Coil Tubings are available in a variety of sizes and can be cut and polished to your specifications. We are a well-known supplier, stockist & distributor of Coil Tubing in a number of standard sizes and grades, including 304/304L and 316/316L, Alloy 625, and Alloy 825. Length: 800-3500M/COIL. Coiled stainless steel tubing is widely used in petrochemical, natural gas, oil and gas, and geothermal applications. Buy SS Coil tube at the best price in China.
Our company is a leading manufacturer of a wide size range & wall thickness of Inconel 625 Seamless Tubing for the aerospace, chemical & pharmaceutical industries. For high corrosion-resistant applications, Alloy 625 Welded tubing is the best option and is used to manufacture aircraft components. Alloy 625 exhaust tubing is a useful material to manufacture high-quality tubing for the oil & gas, food processing, and power generation industries.
| Stainless Steel Coil Tube Parameter | Value Range / Specification |
|---|---|
| Outside Diameter | 6.25MM-25.4mm |
| Thickness | 0.2mm – 2mm |
| Grades | TP - 304, 304L, 316, 316L, 201, ALLOY 625, 825, 2205, etc. |
| Seamless Coil Tubing Specifications | ASTM A213 (average wall) and ASTM A269 |
| Welded Coil Tubing Specifications | ASTM A249 and ASTM A269 |
We offer Stainless Steel Coil Tube in sizes from 6.35 to 25.4 MM and wall thicknesses from 0.2 to 2 mm. Generally, these SS Coil Tubing products are available in lengths up to 3500m. Stainless steel tube straighteners make stainless steel coiled tubing installation faster and easier. We offer a comprehensive range of SS Coil Tubes to our customers in various industry verticals. According to the different applications, the Stainless Steel Seamless Coil Tubes are available in different sizes. We can customize the ideal Stainless Steel Coil Tubing for your unique application. Contact us to confirm availability and pricing.
As a large stockholder of Stainless Steel Coil Tube, we maintain a comprehensive inventory of Stainless Steel 304 Coil Tube, Stainless Steel 304L Coil Tube, Stainless Steel 316 Coil Tube, Stainless Steel 316L Coil Tube, and Stainless Steel 201 Coil Tube.
| Material | Heat | Temperature | Tensile Strength | Yield Strength | Elongation %, Min |
|---|---|---|---|---|---|
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
| U.S.A. | GERMANY | GERMANY | FRANCE | JAPAN | ITALY | SWEDEN | U.K. | E.U. | SPAIN | RUSSIA |
|---|---|---|---|---|---|---|---|---|---|---|
| AISI | DIN 17006 | W.N. 17007 | AFNOR | JIS | UNI | SIS | BSI | EURONORM | ||
| 201 | SUS 201 | |||||||||
| 301 | X 12 CrNi 17 7 | 1.4310 | Z 12 CN 17-07 | SUS 301 | X 12 CrNi 1707 | 23 31 | 301S21 | X 12 CrNi 17 7 | X 12 CrNi 17-07 | |
| 302 | X 5 CrNi 18 7 | 1.4319 | Z 10 CN 18-09 | SUS 302 | X 10 CrNi 1809 | 23 31 | 302S25 | X 10 CrNi 18 9 | X 10 CrNi 18-09 | 12KH18N9 |
| 303 | X 10 CrNiS 18 9 | 1.4305 | Z 10 CNF 18-09 | SUS 303 | X 10 CrNiS 1809 | 23 46 | 303S21 | X 10 CrNiS 18 9 | X 10 CrNiS 18-09 | |
| 303 Se | Z 10 CNF 18-09 | SUS 303 Se | X 10 CrNiS 1809 | 303S41 | X 10 CrNiS 18-09 | 12KH18N10E | ||||
| 304 | X 5 CrNi 18 10 X 5 CrNi 18 12 |
1.4301 1.4303 |
Z 6 CN 18-09 | SUS 304 | X 5 CrNi 1810 | 23 32 | 304S15 304S16 |
X 6 CrNi 18 10 | X 6 CrNi 19-10 | 08KH18N10 06KH18N11 |
| 304 N | SUS 304N1 | X 5 CrNiN 1810 | ||||||||
| 304 H | SUS F 304H | X 8 CrNi 1910 | X 6 CrNi 19-10 | |||||||
| 304 L | X 2 CrNi 18 11 | 1.4306 | Z 2 CN 18-10 | SUS 304L | X 2 CrNi 1911 | 23 52 | 304S11 | X 3 CrNi 18 10 | X 2 CrNi 19-10 | 03KH18N11 |
| X 2 CrNiN 18 10 | 1.4311 | Z 2 CN 18-10-Az | SUS 304LN | X 2 CrNiN 1811 | 23 71 | |||||
| 305 | Z 8 CN 18-12 | SUS 305 | X 8 CrNi 1812 | 23 33 | 305S19 | X 8 CrNi 18 12 | X 8 CrNi 18-12 | |||
| Z 6 CNU 18-10 | SUS XM7 | X 6 CrNiCu 18 10 4 Kd | ||||||||
| 309 | X 15 CrNiS 20 12 | 1.4828 | Z 15 CN 24-13 | SUH 309 | X 16 CrNi 2314 | 309S24 | X 15 CrNi 23 13 | |||
| 309 S | SUS 309S | X 6 CrNi 2314 | X 6 CrNi 22 13 | |||||||
| 310 | X 12 CrNi 25 21 | 1.4845 | SUH 310 | X 22 CrNi 2520 | 310S24 | 20KH23N18 | ||||
| 310 S | X 12 CrNi 25 20 | 1.4842 | Z 12 CN 25-20 | SUS 310S | X 5 CrNi 2520 | 23 61 | X 6 CrNi 25 20 | 10KH23N18 | ||
| 314 | X 15 CrNiSi 25 20 | 1.4841 | Z 12 CNS 25-20 | X 16 CrNiSi 2520 | X 15 CrNiSi 25 20 | 20KH25N20S2 | ||||
| 316 | X 5 CrNiMo 17 12 2 | 1.4401 | Z 6 CND 17-11 | SUS 316 | X 5 CrNiMo 1712 | 23 47 | 316S31 | X 6 CrNiMo 17 12 2 | X 6 CrNiMo 17-12-03 | |
| 316 | X 5 CrNiMo 17 13 3 | 1.4436 | Z 6 CND 17-12 | SUS 316 | X 5 CrNiMo 1713 | 23 43 | 316S33 | X 6 CrNiMo 17 13 3 | X 6 CrNiMo 17-12-03 | |
| 316 L | X 2 CrNiMo 17 13 2 | 1.4404 | Z 2 CND 17-12 | SUS 316L | X 2 CrNiMo 1712 | 23 48 | 316S11 | X 3 CrNiMo 17 12 2 | X 2 CrNiMo 17-12-03 | 03KH17N14M2 |
| 321 | X 6 CrNiTi 18 10 | 1.4541 | Z 6 CNT 18-10 | SUS 321 | X 6 CrNiTi 1811 | 23 37 | 321S31 | X 6 CrNiTi 18 10 | X 6 CrNiTi 18-11 | 08KH18N10T |
| 347 | X 6 CrNiNb 18 10 | 1.4550 | Z 6 CNNb 18-10 | SUS 347 | X 6 CrNiNb 1811 | 23 38 | 347S31 | X 6 CrNiNb 18 10 | X 6 CrNiNb 18-11 | 08KH18N12B |
| 904L | 1.4939 | Z 12 CNDV 12-02 | ||||||||
| UNS31803 | X 2 CrNiMoN 22 5 | 1.4462 | ||||||||
| 410 | X 6 Cr 13 | 1.4000 | Z 10 C 13 | SUS 410 | X 12 Cr 13 | 23 02 | 410S21 | X 12 Cr 13 | X 12 Cr 13 | 12Kh13 |
▼Size of Stainless steel Coil Tube
| ITEM | Grade | Size (MM) | Pressure (Mpa) | Length (M) |
|---|---|---|---|---|
| 1 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/8″×0.025″ | 3200 | 500-2000 |
| 2 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/8″×0.035″ | 3200 | 500-2000 |
| 3 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/4″×0.035″ | 2000 | 500-2000 |
| 4 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/4″×0.049″ | 2000 | 500-2000 |
| 5 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 3/8″×0.035″ | 1500 | 500-2000 |
| 6 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 3/8″×0.049″ | 1500 | 500-2000 |
| 7 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/2″×0.049″ | 1000 | 500-2000 |
| 8 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/2″×0.065″ | 1000 | 500-2000 |
| 9 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ3mm×0.7mm | 3200 | 500-2000 |
| 10 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ3mm×0.9mm | 3200 | 500-2000 |
| 11 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ4mm×0.9mm | 3000 | 500-2000 |
| 12 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ4mm×1.1mm | 3000 | 500-2000 |
| 13 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ6mm×0.9mm | 2000 | 500-2000 |
| 14 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ6mm×1.1mm | 2000 | 500-2000 |
| 15 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ8mm×1mm | 1800 | 500-2000 |
▼Stainless steel coiled tube coiled tubing stock range
| Item | O.D (mm) | 3.0-4.0 | 4.01-6.00 | 6.01-8.00 | 8.01-10.0 | 10.01-12.7 | 12.71-19.05 | 19.05-25.4 |
|---|---|---|---|---|---|---|---|---|
| W.T (mm) | ||||||||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.30-0.40 | √ | √ | √ | ||||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.41-0.50 | √ | √ | √ | √ | |||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.51-0.60 | √ | √ | √ | √ | √ | ||
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.61-0.70 | √ | √ | √ | √ | √ | √ | |
| Stainless Steel Coiled Tubes/ Coil Tubing | 0.71-1.00 | √ | √ | √ | √ | √ | √ | √ |
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.01-1.20 | √ | √ | √ | √ | √ | √ | |
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.21-1.50 | √ | √ | √ | √ | |||
| Stainless Steel Coiled Tubes/ Coil Tubing | 1.51-2.0 | √ | √ | √ |
Our production facilities feature three production lines for stainless steel coiled tubes and pipes. We have more than ten years of exporting experience and are equipped with bending, stretching, saw cutting, stamping, polishing, and other processing equipment. Our stainless steel products are widely used in bathroom fittings, hangers, hardware, condensation heating equipment, and hotel supplies. We welcome domestic and foreign customers to provide drawings or samples.
We have experience exporting stainless steel tube products for more than ten years.
Our production of stainless steel coils has a history of ten years, featuring two production lines that produce continuous welded pipe using advanced technology. We have introduced bright annealing technology, allowing online softening treatment of stainless steel pipe. In addition, we conduct compression testing, flaring, bending, 100% hardness tests, tensile strength testing, and air tightness testing. Prices are reasonable and quality is reliable, with 80% of our coils currently exported worldwide.
Seamless coiled tubing is the preferred choice in critical applications, as it eliminates the risk of impurities often associated with welded coiled tubing.
| Stainless Steel Tubing Coil 3/4 Manufacturer | Stainless Steel Tubing Coil 1/4 Manufacturer |
| 1″ Stainless Steel Coil Tubing Suppliers | Stainless Steel Tubing Coil 1/2 Exporter |
| stainless steel tube coil heat exchanger | stainless steel tube coil suppliers |
| Stainless Steel 304 Seamless Coil Tubing suppliers | Stainless Steel 316 Seamless Coil Tubing suppliers |
| 316 Stainless Steel Coil Tubing Manufacturer | stainless steel cooling coil tube supplier |
| SS 304 Coil Tube Suppliers | SS 316L Coil Tube Manufacturer |
| SS 316 Coil Tube Suppliers | Stainless Steel Welded Coil Tube Suppliers |
| Stainless Steel Seamless Coil Tube Supplier | SS Seamless Coil Tube Supplier |
| Stainless Steel Coil Tubing Supplier | Coil Stainless Steel Tubing Supplier |
| Stainless Steel Coil Tube Supplier | Stainless Steel Coil Tube Exporter |
| 304 Stainless Steel Coil Tube Manufacturer | SS 316L Coil Tube Manufacturer |
| Stainless Steel Coil Tube Size Chart | Stainless Steel Coil Tubing for Sale |
| Stainless Steel Bright Annealed Coil Tube | 304L Stainless Steel Coil Tube Manufacturer |
| Stainless Steel 201 Coil Tubes Supplier | Stainless Steel Coil 316 Tube Supplier |
| 3/8 stainless steel tubing coil Manufacturer | Stainless Steel Coil Tube 304 Manufacturer |
| SS Coil Tube Manufacturer | 316 Stainless Steel Coil Tube Supplier |
| Hot Rolled Stainless Steel Coil Tube supplier | 316L Stainless Steel Coil Tube Supplier |
| 2 Stainless Steel Coil Tube Manufacturer | 201 Stainless Steel Coil Tube Manufacturer |
| 1/2 o.d. x 50' Stainless Steel Coil Tube Supplier | SS 316 Coil Tube Manufacturer |
| food grade stainless steel tubing coil Supplier | Schedule 40 Stainless Steel Coil Tube Supplier |
| 1/2 inch stainless steel coil tubing Supplier | Schedule 80 Stainless Steel Coil Tube Supplier |
| 1/4 inch stainless steel coil tubing Supplier | Schedule 10 Stainless Steel Coil Tube Supplier |
| 3/4 inch stainless steel tubing coil Supplier | Sch 5 Stainless Steel Coil Tube Supplier |
| 1/2 od stainless steel tubing coil Supplier | Stainless Steel Welded Coil Tube Manufacturer |
| 15/16 stainless steel tubing coil Supplier | 1/16 stainless steel tubing coil |
| 13/16 stainless steel tubing coil Supplier | SS 304L Coil Tube Suppliers |
1. What material grades are available for your stainless steel coil tubes?
We supply stainless steel coil tubes in a wide variety of grades, including TP304, TP304L, TP316, TP316L, 201, Alloy 625, Alloy 825, and duplex grades like 2205 and 2507.
2. What are the key dimensional specifications of your coiled tubing?
Our coiled tubing features outside diameters ranging from 6.25mm to 25.4mm and thicknesses from 0.2mm to 2mm. Individual continuous coils can be manufactured in lengths from 800M up to 3500M depending on requirements.
3. What is the difference between seamless and welded stainless steel coil tubes?
Seamless coiled tubing is the preferred choice for critical applications due to its higher reliability and lack of impurities. Welded coiled tubing using premium alloy grades serves as an excellent option for exhaust systems and high-temperature environments.
4. What industrial applications utilize stainless steel coiled tubing?
Our coiled tubes are widely used in refrigeration equipment, evaporators, condensers, geothermal systems, petrochemical processing, CNG piping, boilers, desalination plants, heat exchangers, and oil and gas equipment.
5. What quality testing and treatments do your coiled tubes undergo?
Our tubes undergo advanced bright annealing for uniform softening. Quality control includes compressed air testing, flaring and bending tests, 100% hardness inspections, tensile strength testing, and strict air tightness verification.
