Product Description

stainless steel coil tube stainless steel tube coil stainless steel coil tubing stainless steel coil pipe stainless steel coil tube suppliers stainless steel coil tube manufacturers stainless steel pipe coil

Introduction

Stainless steels are known as high-alloy steels. They are classified into ferritic, austenitic, and martensitic steels based on their crystalline structure.

Grade 310S stainless steel is superior than 304 or 309 stainless steel in most environments, because it has high nickel and chromium content. It has high corrosion resistance and strength in temperatures up to 1149°C (2100°F). The following datasheet gives more details about grade 310S stainless steel.

Stainless Steel Coiled Tubes Specification

Standards: ASTM A269/A249 standard
Grade: TP304, TP316L 304 316 310S 2205 825 625
Trade Name: SS304 Coiled Tubes, SS316 Coiled Tubes, Duplex Coiled Tubes, Monel 400 Coiled Tubes, Hastelloy Coiled Tubes, Inconel coiled Tubes, 904L Coiled Tubes, Seamless Coiled Tubes, Welded Coiled Tubing
Out diameter: 6.52-19.05mm
Thickness: 0.2-2MM
Tolerance: OD± 0.1mm, wall thickness: ±10%, length: ±5mm
Length: 300-3500M/coil
Packaging: iron pallet, wooden pallet, poly bag
Application: refrigeration equipment, evaporator, gas liquid delivery, condenser, beverage machine
State: soft / half hard / soft bright annealing
Specifications: outer diameter 6.52mm-20mm, wall thickness: 0.40mm-1.5mm
Tolerance range: diameter: + 0.1mm, wall thickness: + 10%, length: -0/+6mm
Length: 800-3500M or according to customer requirements.
Product advantages: surface polishing and fine, uniform wall thickness, tolerance precision etc.
Commonly Size: we can product them as your request.

Stainless Steel 310 Coiled Tubes Chemical Composition

The following table shows the chemical composition of grade 310S stainless steel.

Element	Content (%)
Iron, Fe	54
Chromium, Cr	24-26
Nickel, Ni	19-22
Manganese, Mn	2
Silicon, Si	1.50
Carbon, C	0.080
Phosphorous, P	0.045
Sulfur, S	0.030

Physical Properties

The physical properties of grade 310S stainless steel are displayed in the following table.

Properties	Metric	Imperial
Density	8 g/cm³	0.289 lb/in³
Melting point	1455°C	2650°F

Mechanical Properties

The following table outlines the mechanical properties of grade 310S stainless steel.

Properties	Metric	Imperial
Tensile strength	515 MPa	74695 psi
Yield strength	205 MPa	29733 psi
Elastic modulus	190-210 GPa	27557-30458 ksi
Poisson's ratio	0.27-0.30	0.27-0.30
Elongation	40%	40%
Reduction of area	50%	50%
Hardness	95	95

Thermal Properties

The thermal properties of grade 310S stainless steel are given in the following table.

Properties	Metric	Imperial
Thermal conductivity (for stainless 310)	14.2 W/mK	98.5 BTU in/hr ft².°F

Other Designations

Other designations equivalent to grade 310S stainless steel are listed in the following table.

AMS 5521	ASTM A240	ASTM A479	DIN 1.4845
AMS 5572	ASTM A249	ASTM A511	QQ S763
AMS 5577	ASTM A276	ASTM A554	ASME SA240
AMS 5651	ASTM A312	ASTM A580	ASME SA479
ASTM A167	ASTM A314	ASTM A813	SAE 30310S
ASTM A213	ASTM A473	ASTM A814	SAE J405 (30310S)

Alloy 310s Stainless Steel Coiled Tube Sizes

Commonly Size of stainless steel coiled tube: we can product them as your request.

ITEM	Grade	Size (MM)	Pressure (Mpa)	Length (M)
1	316L、304L、304 alloy 625 825 2205 2507	1/8″×0.025″	3200	500-2000
2	316L、304L、304 alloy 625 825 2205 2507	1/8″×0.035″	3200	500-2000
3	316L、304L、304 alloy 625 825 2205 2507	1/4″×0.035″	2000	500-2000
4	316L、304L、304 alloy 625 825 2205 2507	1/4″×0.049″	2000	500-2000
5	316L、304L、304 alloy 625 825 2205 2507	3/8″×0.035″	1500	500-2000
6	316L、304L、304 alloy 625 825 2205 2507	3/8″×0.049″	1500	500-2000
7	316L、304L、304 alloy 625 825 2205 2507	1/2″×0.049″	1000	500-2000
8	316L、304L、304 alloy 625 825 2205 2507	1/2″×0.065″	1000	500-2000
9	316L、304L、304 alloy 625 825 2205 2507	φ3mm×0.7mm	3200	500-2000
10	316L、304L、304 alloy 625 825 2205 2507	φ3mm×0.9mm	3200	500-2000
11	316L、304L、304 alloy 625 825 2205 2507	φ4mm×0.9mm	3000	500-2000
12	316L、304L、304 alloy 625 825 2205 2507	φ4mm×1.1mm	3000	500-2000
13	316L、304L、304 alloy 625 825 2205 2507	φ6mm×0.9mm	2000	500-2000
14	316L、304L、304 alloy 625 825 2205 2507	φ6mm×1.1mm	2000	500-2000
15	316L、304L、304 alloy 625 825 2205 2507	φ8mm×1mm	1800	500-2000
16	316L、304L、304 alloy 625 825 2205 2507	φ8mm×1.2mm	1800	500-2000
17	316L、304L、304 alloy 625 825 2205 2507	φ10mm×1mm	1500	500-2000
18	316L、304L、304 alloy 625 825 2205 2507	φ10mm×1.2mm	1500	500-2000
19	316L、304L、304 alloy 625 825 2205 2507	φ10mm×2mm	500	500-2000
20	316L、304L、304 alloy 625 825 2205 2507	φ12mm×1.5mm	500	500-2000

Our Advantages

We are a stainless steel coiled tube/pipe manufacturer.
We can control the quality of pipe by ourselves.
The length of the pipes is more than 3500M/Coil.
We have experience to export stainless steel tube products for more than ten years.

Stainless Steel Coiled Tubes Other Grades

Stainless Steel 304

Stainless Steel 304L

Stainless Steel 304H

Stainless Steel 316

Stainless Steel 316L

Stainless Steel 316H

Stainless Steel 317L

Stainless Steel 321

Stainless Steel 347

Stainless Steel 410

Stainless Steel 904L

Stainless Steel 310S

Stainless Steel 310

Stainless Steel 310H

Stainless Steel 316Ti

Stainless Steel 321H

Stainless Steel 347H

Seamless Coiled Tubing Features

Seamless coiled tubing is a no. 1 choice in most of the critical applications as there is no risk of impurities that are often associated with welded coiled tubing.

Made available in custom lengths
Improved system safety and reliability
Greater corrosion resistance
Reduces the use of fittings, preventing the possibilities of leaks and other long-term failures
Reduced installation costs – installation involves less time and efforts

Frequently Asked Questions

What are the main advantages of grade 310S stainless steel coiled tubes?

Grade 310S stainless steel is superior in most environments compared to 304 or 309 due to its high nickel and chromium content. It offers outstanding corrosion resistance and maintains high strength in temperatures up to 1149°C (2100°F).

What is the standard and grade availability for your coiled tubing?

Our coiled tubing conforms to ASTM A269/A249 standards. It is available in multiple grades including TP304, TP316L, 304, 316, 310S, 2205, 825, and 625.

Why is seamless coiled tubing preferred over welded coiled tubing?

Seamless coiled tubing is the optimal choice for critical applications because it eliminates the risk of impurities commonly associated with welded tubing. It also improves system safety, provides greater corrosion resistance, reduces leak points by minimizing the need for fittings, and decreases overall installation costs.

In what sizes and dimensions are the coiled tubes supplied?

We offer outer diameters from 6.52mm to 20mm, wall thicknesses from 0.2mm to 2mm, and single coil lengths ranging from 300 to 3500 meters, which can also be customized based on specific requirements.

What are the primary applications of stainless steel coiled tubing?

They are widely used in critical industrial applications including food & beverage industry, boilers, heat exchangers, petrochemicals, CNG piping, desalination plants, geothermal plants, instrumentation, and oil & gas equipment.

What type of packaging is used for shipment?

To ensure maximum protection during transit, our products are securely packaged on iron pallets, wooden pallets, or in protective poly bags.
