Wholesale JIS DIN 304 Stainless steel Precision pipe Supplier, Suppliers

Stianless Steel Pipe /TUBE

stainless steel coil tube
stainless steel tube coil
stainless steel coil tubing
stainless steel coil pipe
stainless steel coil tube suppliers
stainless steel coil tube manufacturers
stainless steel pipe coil

1. : Grade :201 202 304 304l 316 316l

2. Standard:ASTM DIN JIS AISI GB

3.Surface: 2B BA NO.4 Mirror 320# 380# 400#600# 800#

4.Length :6M 11.5 M 12M or As Per your requirment.

5.OD :Round Tube 9.52-219MM Retangle :10*10-150-150

6.Inner packing :Plastic Bag

7.Outer Packing: Carton /Woven/Wooden Packaging

8.Od:+/- 0.2mm, Thickness: +/- 0.02mm

Send Inquiry

Product Description

Stainless Steel Coil Products

stainless steel coil tube stainless steel tube coil stainless steel coil tubing stainless steel coil pipe stainless steel coil tube suppliers stainless steel coil tube manufacturers stainless steel pipe coil

JIS DIN 304 Stainless steel Precision pipe

Stainless steel pipe is one of the more standardized materials in the building and engineering industries. Stainless Steel Seamless Pipes is a hollow steel bar, a large number of pipes used for conveying fluids, such as oil, gas, water, gas, steam, heat exchanger, mechanical machine.

📋 Specifications & Keywords Reference

stainless steel coil tube stainless steel tube coil stainless steel coil tubing stainless steel coil pipe stainless steel coil tube suppliers stainless steel coil tube manufacturers stainless steel pipe coil

Standard ASTM A-312, ASTM A-269, ASTM A-632, ASTM A-213, DIN 17458, DIN 17456, JIS G3463, JIS G3459, JIS G3448

Material Grade 201 / 202 / 304 / 316

Outer Diameter 0.1mm - 8mm

Thickness 0.05mm - 2.1mm

Length 2440mm, 3050mm, 5800mm, 6000mm, 6100mm or as customer request

Tolerance a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 10% OR as customer request
c) Length: +/- 10mm

Surface Finish Satin / Hairline: 180#, 320#

Polish 400#, 600#, 800# or Mirror surface

Application Processed into railings, handrails, doors and Windows

PACKING Plastic bag / woven packing (please send details packing to us if you have other requirements)

🧪 Chemical Composition (Standard Grades)

Grade	C (Max)	Mn (Max)	P (Max)	S (Max)	Si (Max)	Cr	Ni	Mo	N (Max)	Cu/Others
304	0.08	2	0.045	0.03	1	18.00-20.00	8.00-10.50	-	0.1	-
304L	0.03	2	0.045	0.03	1	18.00-20.00	8.00-12.00	-	0.1	-
310S	0.08	2	0.045	0.03	1.5	24.00-26.00	19.00-22.00	-	-	-
316	0.08	2	0.045	0.03	1	16.00-18.00	10.00-14.00	2.00-3.00	-	-
316L	0.03	2	0.045	0.03	1	16.00-18.00	10.00-14.00	2.00-3.00	0.1	-

📊 Element Composition Matrix

Element	201	202	304	316	S31803	S32750
C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.030	≤0.030
Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00	≤0.80
Mn	5.5-7.5	7.5-10.0	≤2.00	≤2.00	≤2.00	≤1.20
P	≤0.060	≤0.060	≤0.045	≤0.045	≤0.030	≤0.035
S	≤0.030	≤0.030	≤0.030	≤0.030	≤0.020	≤0.020
Cr	16-18	17-19	18-20	16-18	21-23	21-23
Ni	3.5-5.5	4.0-6.0	42958	43022	4.5-6.5	6.0-8.0
Mo	-	-	-	2.0-3.0	2.5-3.5	3.0-5.0
N	≤0.25	≤0.25	-	-	0.08-0.2	0.24-0.32
Cu	-	-	-	-	≤0.50	-

⚙️ Mechanical Properties

Material Item	201	202	304	316	S31803	S32750
Tensile Strength (MPa)	≥655	≥620	≥515	≥515	≥620	≥800
Yield Strength (MPa)	≥260	≥310	≥205	≥205	≥450	≥550
Elongation (%)	≥35	≥35	≥35	≥35	≥25	≥15
Hardness (HV)	≤230	≤230	≤200	≤200	≤303	≤323

🔩 Product Standards & Processing Requirements

✦ Marking: Material grade, standard, specification, heat no.

✦ Surface Treatment: Bright annealed, polished outside and inside surface.

✦ Package: Knitting strip bundle, wooden box or steel box.

✦ Mill Test Certificate: According to EN 10204 3.2.

✦ Inspection: Third party inspection, or by clients.

📐 Steel Tube Dimensions (Square, Rectangular, Round)

Square Steel Tube (mm)	Rectangular Steel Tube (mm)	Round Steel Tube (mm)
10×10×0.6~3.0	10×20×0.6~3.0	6x0.6~1.0
15×15×0.6~3.0	20×30×0.6~3.0	12x0.6~1.5
20×20×0.6~3.0	20×40×0.6~3.0	13x0.6~1.5
25×25×0.6~3.0	25×50×0.6~3.5	16x0.6~2.0
30×30×0.6~3.5	30×50×0.6~3.5	19x0.6~3.0
40×40×0.6~3.5	40×60×0.6~3.5	20x0.6~3.0
50×50×0.6~3.5	40×80×0.6~3.5	22x0.6~3.0
60×60×0.6~3.5	60×80×1.0~6.0	25x0.6~3.0
70×70×0.6~3.5	50×100×1.0~6.0	27x0.6~3.0
75×75×0.6~3.5	60×120×1.0~6.0	32x0.6~3.0
80×80×1.0~6.0	80×120×2.0~8.0	40x0.6~3.5
100×100×2.0~8.0	80×160×2.0~8.0	38x0.6~3.0
120×120×2.0~8.0	100×150×2.0~8.0	48x0.6~3.5
150×150×2.0~8.0	100×200×2.0~8.0	60x0.6~3.5
200×200×4.0~16.0	150×250×4.0~12.0	76x0.6~3.5
250×250×4.0~16.0	200×300×4.0~16.0	89x1.0~6.0
300×300×4.0~16.0	300×400×4.0~16.0	104x1.0~6.0
400×400×4.0~16.0	300×500×4.0~16.0	114x1.0~6.0

The physical properties of stainless steel polishing pipe:

Grade	Composition, %
Grade	Carbon, max	Manganese, max	Phosphorus, max	Sulfur, max	Silicon, max	Nickel	Chromium	Molybdenum	Titanium	Columbium + Tantalum
Austenitic
301	0.15	2.00	0.040	0.030	1.00	6.0–8.0	16.0–18.0	...	...	...
302	0.15	2.00	0.040	0.030	1.00	8.0–10.0	17.0–19.0	...	...	...
304	0.08	2.00	0.040	0.030	1.00	8.0–11.0	18.0–20.0	...	...	...
304L	0.035A	2.00	0.040	0.030	1.00	8.0–13.0	18.0–20.0	...	...	...
305	0.12	2.00	0.040	0.030	1.00	10.0–13.0	17.0–19.0	...	...	...
309S	0.08	2.00	0.040	0.030	1.00	12.0–15.0	22.0–24.0	...	...	. . .
309S-Cb	0.08	2.00	0.040	0.030	1.00	12.0–15.0	22.0–24.0	...	...	B
310S	0.08	2.00	0.040	0.030	1.00	19.0–22.0	24.0–26.0	...	...	...
316	0.08	2.00	0.040	0.030	1.00	10.0–14.0	16.0–18.0	2.0–3.0	...	...
316L	0.035A	2.00	0.040	0.030	1.00	10.0–15.0	16.0–18.0	2.0–3.0	...	...
317	0.08	2.00	0.040	0.030	1.00	11.0–14.0	18.0–20.0	3.0–4.0	...	...
321	0.08	2.00	0.040	0.030	1.00	9.0–13.0	17.0–20.0	...	C	...
330	0.15	2.00	0.040	0.030	1.00	33.0–36.0	14.0–16.0	...	...	...
347	0.08	2.00	0.040	0.030	1.00	9.0–13.0	17.0–20.0	...	...	B
429	0.12	1.00	0.040	0.030	1.00	0.50 max	14.0–16.0	...	...	...
430	0.12	1.00	0.040	0.030	1.00	0.50 max	16.0–18.0	...	...	...
430-Ti	0.10	1.00	0.040	0.030	1.00	0.075 max	16.0–19.5	...	5 × C min,	...
									0.75 max

🌍 Stainless Steel Coiled Tubing Material Grade Standards

U.S.A. (AISI)	GERMANY (DIN 17006)	GERMANY (W.N. 17007)	FRANCE (AFNOR)	JAPAN (JIS)	ITALY (UNI)	SWEDEN (SIS)	U.K. (BSI)	E.U. (EURONORM)
201	-	-	-	SUS 201	-	-	-	-
301	X 12 CrNi 17 7	1.4310	Z 12 CN 17-07	SUS 301	X 12 CrNi 1707	23 31	301S21	X 12 CrNi 17 7
302	X 5 CrNi 18 7	1.4319	Z 10 CN 18-09	SUS 302	X 10 CrNi 1809	23 31	302S25	X 10 CrNi 18 9
303	X 10 CrNiS 18 9	1.4305	Z 10 CNF 18-09	SUS 303	X 10 CrNiS 1809	23 46	303S21	X 10 CrNiS 18 9
303 Se	-	-	Z 10 CNF 18-09	SUS 303 Se	X 10 CrNiS 1809	-	303S41	-
304	X 5 CrNi 18 10 X 5 CrNi 18 12	1.4301 1.4303	Z 6 CN 18-09	SUS 304	X 5 CrNi 1810	23 32	304S15 304S16	X 6 CrNi 18 10
304 N	-	-	-	SUS 304N1	X 5 CrNiN 1810	-	-	-
304 H	-	-	-	SUS F 304H	X 8 CrNi 1910	-	-	-
304 L	X 2 CrNi 18 11	1.4306	Z 2 CN 18-10	SUS 304L	X 2 CrNi 1911	23 52	304S11	X 3 CrNi 18 10
305	-	-	Z 8 CN 18-12	SUS 305	X 8 CrNi 1812	23 33	305S19	X 8 CrNi 18 12
309	X 15 CrNiS 20 12	1.4828	Z 15 CN 24-13	SUH 309	X 16 CrNi 2314	-	309S24	X 15 CrNi 23 13
309 S	-	-	-	SUS 309S	X 6 CrNi 2314	-	-	X 6 CrNi 22 13
310	X 12 CrNi 25 21	1.4845	-	SUH 310	X 22 CrNi 2520	-	310S24	-
310 S	X 12 CrNi 25 20	1.4842	Z 12 CN 25-20	SUS 310S	X 5 CrNi 2520	23 61	-	X 6 CrNi 25 20
314	X 15 CrNiSi 25 20	1.4841	Z 12 CNS 25-20	-	X 16 CrNiSi 2520	-	-	X 15 CrNiSi 25 20
316	X 5 CrNiMo 17 12 2	1.4401	Z 6 CND 17-11	SUS 316	X 5 CrNiMo 1712	23 47	316S31	X 6 CrNiMo 17 12 2
316 L	X 2 CrNiMo 17 13 2	1.4404	Z 2 CND 17-12	SUS 316L	X 2 CrNiMo 1712	23 48	316S11	X 3 CrNiMo 17 12 2
317	-	-	-	SUS 317	X 5 CrNiMo 1815	23 66	317S16	-
317 L	X 2 CrNiMo 18 16 4	1.4438	Z 2 CND 19-15	SUS 317L	X 2 CrNiMo 1815	23 67	317S12	X 3 CrNiMo 18 16 4
321	X 6 CrNiTi 18 10	1.4541	Z 6 CNT 18-10	SUS 321	X 6 CrNiTi 1811	23 37	321S31	X 6 CrNiTi 18 10
347	X 6 CrNiNb 18 10	1.4550	Z 6 CNNb 18-10	SUS 347	X 6 CrNiNb 1811	23 38	347S31	X 6 CrNiNb 18 10
904L	-	1.4939	Z 12 CNDV 12-02	-	-	-	-	-
UNS31803	X 2 CrNiMoN 22 5	1.4462	-	-	-	-	-	-
UNS32760	X 3 CrNiMoN 25 7	1.4501	Z 3 CND 25-06Az	-	-	-	-	-
403	X 6 Cr 13	1.4000	Z 12 C 13	SUS 403	X 12 Cr 13	23 02	403S17	X 10 Cr 13
405	X 6 CrAl 13	1.4002	Z 6 CA 13	SUS 405	X 6 CrAl 13	-	405S17	X 6 CrAl 13
409	X 6 CrTi 12	1.4512	Z 6 CT 12	SUH 409	X 6 CrTi 12	-	409S19	X 5 CrTi 12
410	X 6 Cr 13	1.4000	Z 10 C 13	SUS 410	X 12 Cr 13	23 02	410S21	X 12 Cr 13
410 S	X 6 Cr 13	1.4000	Z 6 C 13	SUS 410S	X 6 Cr 13	23 01	403S17	X 6 Cr 13

🏭 Production Facility

🛡️ Quality Advantage

The quality of our products for the control line in oil and gas sector is assured not just during the controlled manufacturing process but also by way of finished product testing. Typical tests include:

Non-destructive tests
Hydrostatic tests
Surface finish controls
Dimensional accuracy measurements
Flare and coning tests
Mechanical and chemical property testing

💡 Application Capillary Tube

Medical device industry
Temperature-guided industrial temperature control, sensors used pipe, tube thermometer
Pens care industry core tube
Micro-tube antenna, various types of small precision stainless steel antenna
With a variety of electronic small-diameter Stainless steel capillary
Jewelry needle punch
Watches, picture
Car antenna tube, bar antennas using tubes, antenna tube
Laser engraving equipment to use stainless steel tube
Fishing gear, accessories, Yugan out with possession of
Diet with stainless steel capillary
All types of mobile phone stylus & a computer stylus
Heating pipe industry, oil industry
Printers, silent box needle
Pull a double-melt stainless steel tube used in window-coupled
A variety of industrial small diameter Precision stainless steel tubes
Precision dispensing with stainless steel needles
Microphone, headphones and microphone to use stainless steel tube, and so on

📸 Product Gallery & Packaging

Frequently Asked Questions (FAQ)

What standards do your stainless steel coil tubes comply with?

Our stainless steel coil tubes are manufactured in compliance with major international standards, including ASTM A-312, ASTM A-269, ASTM A-632, ASTM A-213, DIN 17458, DIN 17456, and JIS G3463/G3459/G3448.

What are the available material grades for these coil tubes?

We supply products in multiple material grades, including standard Austenitic grades such as 201, 202, 304, 304L, 310S, 316, 316L, 317L, 321, 347, and duplex grades like UNS S31803 and UNS S32750.

What size ranges do you offer for stainless steel precision coiled tubing?

Our outer diameter (OD) ranges from 0.1mm to 8mm, with wall thicknesses spanning from 0.05mm to 2.1mm. Lengths can be customized to 2440mm, 3050mm, 5800mm, 6000mm, 6100mm, or tailored to customer requests.

How is the quality of the control line tubing ensured?

Quality is maintained through a combination of controlled manufacturing and finished product tests. These include non-destructive tests, hydrostatic testing, surface finish inspections, dimensional checks, flare/coning tests, and mechanical/chemical analysis.

What surface treatments are available for stainless steel coil tubing?

We provide Bright Annealed (BA) finish as well as polished inside and outside surfaces. Polishing specs include Satin/Hairline (180#, 320#) and high polish finishes (400#, 600#, 800# or Mirror finish).

What are the typical applications for precision capillary tubes?

Capillary tubes are widely used in medical devices, temperature sensors and industrial controls, instrumentation, electronic micro-tubes, car antennas, laser engraving setups, and high-precision dispensing equipment.
