Wholesale astm a269 304 stainless steel control tube Manufacturers, Suppliers

Liao cheng SIhe stainless steel material Co.,LTD, produce our hot-selling Stainless Steel 304 Control Line to you. The best quality and best price , We become a leader in Stainless Steel Hydraulic Control Lines’ field. Our Control Lines are supplied to all around the world. The mechanical properties and chemical composition of our control Lines are in full compliance with the standard, and the Control Lines can accept SSC and HIC tests , hydraulic tests and PMI tests. We can provide various test related certificates .SIhe stainless steel material Co.,LTD, which is one of the reputed manufacturer, supplier & ASTM A269 standard exporter stainless Steel Capillary Tubing and Coiled Tubing/Control Line, We specialize in the supply of high quality Seamless Hydraulic Line in stainless steel 316 and 304 grades which are highly resistant to corrosion. SS Hydraulic Control Line is the preferred choice for most applications due to greater corrosion resistance and precision. We ensure the highest surface quality in all of our SS Coiled Tubing. We offered 304l stainless steel coiled tube control Line , which are polished, cleaned, passivated and are ready for immediate use. We are also well known stainless steel Capillary Tubing and Hydraulic Control Lines Manufacturer in China. Buy SS Control Line at best price in China from us as compared to the market price. We are Sincerely look forward to cooperate with

Send Inquiry

Product Description

304 grade Stainless Steel Coiled Tube, 304 stainless steel capillary Coiled Tube, 304 Hydraulic Control Line, Duplex 2205 Coiled tubing Control Line, Monel400, Inconel 825 Coiled tubing Control Line, and Stainless steel Control Line.

Common Grade

TP304, TP304L, TP304H
TP321, TP321H
TP316L, TP316SS, TP316Ti
TP347, TP347H, TP317L
TP309S, TP310S, 904L

Standard Specifications

Russian: 08X18H10, 03X18H11, 10X17H13M2T, 03X17H13M2, 12X18H10T, 08X18H10T, 08X18H12B
German: 1.4301, 1.4306, 1.4541, 1.4404, 1.4571, 1.4550
Japanese: SUS304, SUS304L, SUS321, SUS316L, SUS316Ti, SUS347, SUS800, SUS840

Duplex & Special Alloys

Double-Grade: 304/304L, 316/316L, 321/321H, 347/347H
Super Duplex: 2205, 2304, S31803, S32750
Inconel & Incoloy: Inconel 600/601/625/725, Incoloy 800/800H/800HT/825/901/925/926

Standard Stainless Steel Control Line Pressure & Length

Seamless Stainless Steel Coiled Tubing Control Line Common Sizes
ITEM	Material Grade	Size (mm / inch)	Length (Meters)	Pressure (Mpa)
1	304L 304 316 316L 904L 310S 625 825 2205 2507	1/8″ × 0.025″	3200	80
2	304L 304 316 316L 904L 310S 625 825 2205 2507	1/8″ × 0.035″	3200	100
3	304L 304 316 316L 904L 310S 625 825 2205 2507	1/4″ × 0.035″	2000	100
4	304L 304 316 316L 904L 310S 625 825 2205 2507	1/4″ × 0.049″	2000	100
5	304L 304 316 316L 904L 310S 625 825 2205 2507	3/8″ × 0.035″	1500	80
6	304L 304 316 316L 904L 310S 625 825 2205 2507	3/8″ × 0.049″	1500	100
7	304L 304 316 316L 904L 310S 625 825 2205 2507	1/2″ × 0.049″	1000	80
8	304L 304 316 316L 904L 310S 625 825 2205 2507	1/2″ × 0.065″	1000	100
9	304L 304 316 316L 904L 310S 625 825 2205 2507	φ3mm × 0.7mm	3200	80
10	304L 304 316 316L 904L 310S 625 825 2205 2507	φ3mm × 0.9mm	3200	100
11	304L 304 316 316L 904L 310S 625 825 2205 2507	φ4mm × 0.9mm	3000	100
12	304L 304 316 316L 904L 310S 625 825 2205 2507	φ4mm × 1.1mm	3000	100
13	304L 304 316 316L 904L 310S 625 825 2205 2507	φ6mm × 0.9mm	2000	100
14	304L 304 316 316L 904L 310S 625 825 2205 2507	φ6mm × 1.1mm	2000	100
15	304L 304 316 316L 904L 310S 625 825 2205 2507	φ8mm × 1.0mm	1800	80
16	304L 304 316 316L 904L 310S 625 825 2205 2507	φ8mm × 1.2mm	1800	100
17	304L 304 316 316L 904L 310S 625 825 2205 2507	φ10mm × 1.0mm	1500	70
18	304L 304 316 316L 904L 310S 625 825 2205 2507	φ10mm × 1.2mm	1500	70
19	304L 304 316 316L 904L 310S 625 825 2205 2507	φ10mm × 2.0mm	500	100
20	304L 304 316 316L 904L 310S 625 825 2205 2507	φ12mm × 1.5mm	500	80

Seamless Stainless Steel Control Line Product Specifications

Thickness	0.1 to 2mm
Material Grade	304, 304L, 316, 316L, 321, 316Ti, 904L, Duplex 2205, Monel400, Inconel 625, Inconel 825
Diameter	1.5 to 15 mm OD, 1/4 inch, 3/8 inch in stock. Common stock sizes: 6.35mm1.24mm, 80.5mm, 80.8mm, 60.89mm, 81mm, 9.531.24mm, 10*1mm, etc.
Shape	Round
Unit Pipe Length	Coils of at least 8,000 feet to 10,000 feet (Length can be customized)
Range & Size	All sizes and lengths available as per requirements
Surface Finish	Bright annealed, Polished soft inner and outer in clean condition
Pipe Fluid	Chemical, Water, Gas, Oil
Minimum Order Quantity	500 kgs

Related Applications & Specifications

Medical Acupuncture with Coiled Tubing Control Line

High-pressure instrumentation with Coiled Tubing Control Line

Coal exploration with a stainless steel Control Line

Thermostat with Control Line

Beer machine with stainless steel Control Line

Drinking water equipment with stainless steel Control Line

Danfoss expansion valve with stainless steel Coiled Tubing Control Line

Standard Specifications: Outer diameter range of 0.3mm to 10mm with tight tolerance control of 0.005mm to 0.01mm.

Frequently Asked Questions

Q: What grades of stainless steel and alloys are available for your coiled tubing?

We offer coiled tubing in a wide range of materials including standard 304, 304L, 316, and 316L, duplex steels like 2205 and S32750, as well as high-performance alloys such as Monel 400, Inconel 625, and Incoloy 825.

Q: What is the pressure rating and standard length for your control lines?

Our standard control lines are designed to handle working pressures ranging from 70 Mpa to 100 Mpa. Depending on the outer diameter and thickness, single-coil continuous lengths can reach up to 1,000 to 3,200 meters.

Q: Can you customize the length and dimensions of the coiled tubing?

Yes, we can produce continuous seamless coiled tubing in lengths from 8,000 feet to 10,000 feet per coil, and all dimensions and specific lengths can be customized based on your technical application requirements.

Q: What surface finishes do you provide for capillary coiled tubes?

Our tubes are supplied with a bright annealed finish, featuring a polished and soft inner and outer surface that is completely clean and ready for precision fluid applications.

Q: What is the minimum order quantity (MOQ) for these products?

Our minimum order quantity for standard and customized seamless stainless steel coiled tubing is 500 kgs.
