Stainless steels are known as high-alloy steels. They are classified into ferritic, austenitic, and martensitic steels based on their crystalline structure.
Grade 310S stainless steel is superior than 304 or 309 stainless steel in most environments, because it has high nickel and chromium content. It has high corrosion resistance and strength in temperatures up to 1149°C (2100°F). The following datasheet gives more details about grade 310S stainless steel.
The following table shows the chemical composition of grade 310S stainless steel.
| Element | Content (%) |
|---|---|
| Iron, Fe | 54 |
| Chromium, Cr | 24-26 |
| Nickel, Ni | 19-22 |
| Manganese, Mn | 2 |
| Silicon, Si | 1.50 |
| Carbon, C | 0.080 |
| Phosphorous, P | 0.045 |
| Sulfur, S | 0.030 |
The physical properties of grade 310S stainless steel are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8 g/cm³ | 0.289 lb/in³ |
| Melting point | 1455°C | 2650°F |
The following table outlines the mechanical properties of grade 310S stainless steel.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 515 MPa | 74695 psi |
| Yield strength | 205 MPa | 29733 psi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson's ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation | 40% | 40% |
| Reduction of area | 50% | 50% |
| Hardness | 95 | 95 |
The thermal properties of grade 310S stainless steel are given in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Thermal conductivity (for stainless 310) | 14.2 W/mK | 98.5 BTU in/hr ft².°F |
Other designations equivalent to grade 310S stainless steel are listed in the following table.
| AMS 5521 | ASTM A240 | ASTM A479 | DIN 1.4845 |
| AMS 5572 | ASTM A249 | ASTM A511 | QQ S763 |
| AMS 5577 | ASTM A276 | ASTM A554 | ASME SA240 |
| AMS 5651 | ASTM A312 | ASTM A580 | ASME SA479 |
| ASTM A167 | ASTM A314 | ASTM A813 | SAE 30310S |
| ASTM A213 | ASTM A473 | ASTM A814 | SAE J405 (30310S) |
| Size of Stainless steel Coil Tube | ||||
|---|---|---|---|---|
| ITEM | Grade | Size (MM) | Pressure (Mpa) | Length (M) |
| 1 | 316L、304L、304 alloy 625 825 2205 2507 | 1/8″×0.025″ | 3200 | 500-2000 |
| 2 | 316L、304L、304 alloy 625 825 2205 2507 | 1/8″×0.035″ | 3200 | 500-2000 |
| 3 | 316L、304L、304 alloy 625 825 2205 2507 | 1/4″×0.035″ | 2000 | 500-2000 |
| 4 | 316L、304L、304 alloy 625 825 2205 2507 | 1/4″×0.049″ | 2000 | 500-2000 |
| 5 | 316L、304L、304 alloy 625 825 2205 2507 | 3/8″×0.035″ | 1500 | 500-2000 |
| 6 | 316L、304L、304 alloy 625 825 2205 2507 | 3/8″×0.049″ | 1500 | 500-2000 |
| 7 | 316L、304L、304 alloy 625 825 2205 2507 | 1/2″×0.049″ | 1000 | 500-2000 |
| 8 | 316L、304L、304 alloy 625 825 2205 2507 | 1/2″×0.065″ | 1000 | 500-2000 |
| 9 | 316L、304L、304 alloy 625 825 2205 2507 | φ3mm×0.7mm | 3200 | 500-2000 |
| 10 | 316L、304L、304 alloy 625 825 2205 2507 | φ3mm×0.9mm | 3200 | 500-2000 |
| 11 | 316L、304L、304 alloy 625 825 2205 2507 | φ4mm×0.9mm | 3000 | 500-2000 |
| 12 | 316L、304L、304 alloy 625 825 2205 2507 | φ4mm×1.1mm | 3000 | 500-2000 |
| 13 | 316L、304L、304 alloy 625 825 2205 2507 | φ6mm×0.9mm | 2000 | 500-2000 |
| 14 | 316L、304L、304 alloy 625 825 2205 2507 | φ6mm×1.1mm | 2000 | 500-2000 |
| 15 | 316L、304L、304 alloy 625 825 2205 2507 | φ8mm×1mm | 1800 | 500-2000 |
| 16 | 316L、304L、304 alloy 625 825 2205 2507 | φ8mm×1.2mm | 1800 | 500-2000 |
| 17 | 316L、304L、304 alloy 625 825 2205 2507 | φ10mm×1mm | 1500 | 500-2000 |
| 18 | 316L、304L、304 alloy 625 825 2205 2507 | φ10mm×1.2mm | 1500 | 500-2000 |
| 19 | 316L、304L、304 alloy 625 825 2205 2507 | φ10mm×2mm | 500 | 500-2000 |
| 20 | 316L、304L、304 alloy 625 825 2205 2507 | φ12mm×1.5mm | 500 | 500-2000 |
★ Seamless coiled tubing is a no. 1 choice in most of the critical applications as there is no risk of impurities that are often associated with welded coiled tubing.
We have experience to export stainless steel tube products for more than ten years.
Grade 310S contains high nickel and chromium content, offering higher corrosion resistance and mechanical strength in environments with temperatures reaching up to 1149°C (2100°F).
It is widely used in refrigeration equipment, evaporators, condensers, gas-liquid delivery systems, heat exchangers, petrochemical processing, and oil and gas piping setups.
Seamless coiled tubing eliminates the risk of impurities commonly associated with welded seams. It offers better system safety, higher corrosion resistance, and fewer fittings, which reduces the potential for leak failures.
Outer diameters range from 6.52mm to 20mm with wall thicknesses between 0.2mm and 2mm. Lengths can extend from 300 to 3500 meters per coil depending on customer requests.
Our coiled tubes are manufactured under ASTM A269/A249 standards. Available designations include TP304, TP316L, 310S, 2205, Monel 400, Hastelloy, and Inconel alloys.
