Grade 316 is the standard molybdenum-bearing grade, second in importance to 304 amongst the austenitic stainless steels. The molybdenum gives 316 better overall corrosion resistant properties than Grade 304, particularly higher resistance to pitting and crevice corrosion in chloride environments.
Grade 316L, the low carbon version of 316 and is immune from sensitisation (grain boundary carbide precipitation). Thus it is extensively used in heavy gauge welded components (over about 6mm). There is commonly no appreciable price difference between 316 and 316L stainless steel.
The austenitic structure also gives these grades excellent toughness, even down to cryogenic temperatures.
Compared to chromium-nickel austenitic stainless steels, 316L stainless steel offers higher creep, stress to rupture and tensile strength at elevated temperatures.
These properties are specified for flat rolled product (plate, sheet and coil) in ASTM A240/A240M. Similar but not necessarily identical properties are specified for other products such as pipe and bar in their respective specifications.
| Grade | Condition | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|---|
| 316L | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 |
Table 2. Mechanical properties for 316L grade.
| Grade | Tensile Str (MPa) min | Yield Str 0.2% Proof (MPa) min | Elong (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316L | 485 | 170 | 40 | 95 | 217 |
Table 3. Typical physical properties for 316 grade stainless steels.
| Grade | Density (kg/m³) | Elastic Modulus (GPa) | Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Elec Resistivity (nΩ.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-315°C | 0-538°C | At 100°C | At 500°C | |||||
| 316/L/H | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Table 4. Grade specifications for 316L stainless steels.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | Name | ||||
| 316L | S31603 | 316S11 | - | 1.4404 | X2CrNiMo17-12-2 | 2348 | SUS 316L |
| Size of Stainless Steel Coil Tube | ||||
|---|---|---|---|---|
| ITEM | Grade | Size (MM / Inch) | Pressure (Mpa) | Length (M) |
| 1 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/8″ × 0.025″ | 3200 | 500-2000 |
| 2 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/8″ × 0.035″ | 3200 | 500-2000 |
| 3 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/4″ × 0.035″ | 2000 | 500-2000 |
| 4 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/4″ × 0.049″ | 2000 | 500-2000 |
| 5 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 3/8″ × 0.035″ | 1500 | 500-2000 |
| 6 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 3/8″ × 0.049″ | 1500 | 500-2000 |
| 7 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/2″ × 0.049″ | 1000 | 500-2000 |
| 8 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | 1/2″ × 0.065″ | 1000 | 500-2000 |
| 9 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ3mm × 0.7mm | 3200 | 500-2000 |
| 10 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ3mm × 0.9mm | 3200 | 500-2000 |
| 11 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ4mm × 0.9mm | 3000 | 500-2000 |
| 12 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ4mm × 1.1mm | 3000 | 500-2000 |
| 13 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ6mm × 0.9mm | 2000 | 500-2000 |
| 14 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ6mm × 1.1mm | 2000 | 500-2000 |
| 15 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ8mm × 1mm | 1800 | 500-2000 |
| 16 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ8mm × 1.2mm | 1800 | 500-2000 |
| 17 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ10mm × 1mm | 1500 | 500-2000 |
| 18 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ10mm × 1.2mm | 1500 | 500-2000 |
| 19 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ10mm × 2mm | 500 | 500-2000 |
| 20 | 316L, 304L, 304, Alloy 625, 825, 2205, 2507 | φ12mm × 1.5mm | 500 | 500-2000 |
We are a stainless steel coiled tube/pipe manufacturer. We can control the quality of the pipe ourselves. The length of the pipes is more than 3500M/Coil.
| U.S.A. | GERMANY | GERMANY | FRANCE | JAPAN | ITALY | SWEDEN | U.K. | E.U. | SPAIN | RUSSIA |
|---|---|---|---|---|---|---|---|---|---|---|
| AISI | DIN 17006 | W.N. 17007 | AFNOR | JIS | UNI | SIS | BSI | EURONORM | - | - |
| 201 | - | - | - | SUS 201 | - | - | - | - | - | - |
| 301 | X 12 CrNi 17 7 | 1.4310 | Z 12 CN 17-07 | SUS 301 | X 12 CrNi 1707 | 23 31 | 301S21 | X 12 CrNi 17 7 | X 12 CrNi 17-07 | - |
| 302 | X 5 CrNi 18 7 | 1.4319 | Z 10 CN 18-09 | SUS 302 | X 10 CrNi 1809 | 23 31 | 302S25 | X 10 CrNi 18 9 | X 10 CrNi 18-09 | 12KH18N9 |
| 303 | X 10 CrNiS 18 9 | 1.4305 | Z 10 CNF 18-09 | SUS 303 | X 10 CrNiS 1809 | 23 46 | 303S21 | X 10 CrNiS 18 9 | X 10 CrNiS 18-09 | - |
| 303 Se | - | - | Z 10 CNF 18-09 | SUS 303 Se | X 10 CrNiS 1809 | - | 303S41 | - | X 10 CrNiS 18-09 | 12KH18N10E |
| 304 | X 5 CrNi 18 10 X 5 CrNi 18 12 | 1.4301 1.4303 | Z 6 CN 18-09 | SUS 304 | X 5 CrNi 1810 | 23 32 | 304S15 304S16 | X 6 CrNi 18 10 | X 6 CrNi 19-10 | 08KH18N10 06KH18N11 |
| 304 N | - | - | - | SUS 304N1 | X 5 CrNiN 1810 | - | - | - | - | - |
| 304 H | - | - | - | SUS F 304H | X 8 CrNi 1910 | - | - | - | X 6 CrNi 19-10 | - |
| 304 L | X 2 CrNi 18 11 | 1.4306 | Z 2 CN 18-10 | SUS 304L | X 2 CrNi 1911 | 23 52 | 304S11 | X 3 CrNi 18 10 | X 2 CrNi 19-10 | 03KH18N11 |
| - | X 2 CrNiN 18 10 | 1.4311 | Z 2 CN 18-10-Az | SUS 304LN | X 2 CrNiN 1811 | 23 71 | - | - | - | - |
| 305 | - | - | Z 8 CN 18-12 | SUS 305 | X 8 CrNi 1812 | 23 33 | 305S19 | X 8 CrNi 18 12 | X 8 CrNi 18-12 | - |
| - | - | - | Z 6 CNU 18-10 | SUS XM7 | - | - | - | X 6 CrNiCu 18 10 4 Kd | - | - |
| 309 | X 15 CrNiS 20 12 | 1.4828 | Z 15 CN 24-13 | SUH 309 | X 16 CrNi 2314 | - | 309S24 | X 15 CrNi 23 13 | - | - |
| 309 S | - | - | - | SUS 309S | X 6 CrNi 2314 | - | - | X 6 CrNi 22 13 | - | - |
| 310 | X 12 CrNi 25 21 | 1.4845 | - | SUH 310 | X 22 CrNi 2520 | - | 310S24 | - | - | 20KH23N18 |
| 310 S | X 12 CrNi 25 20 | 1.4842 | Z 12 CN 25-20 | SUS 310S | X 5 CrNi 2520 | 23 61 | - | X 6 CrNi 25 20 | - | 10KH23N18 |
| 314 | X 15 CrNiSi 25 20 | 1.4841 | Z 12 CNS 25-20 | - | X 16 CrNiSi 2520 | - | - | X 15 CrNiSi 25 20 | - | 20KH25N20S2 |
| 316 | X 5 CrNiMo 17 12 2 | 1.4401 | Z 6 CND 17-11 | SUS 316 | X 5 CrNiMo 1712 | 23 47 | 316S31 | X 6 CrNiMo 17 12 2 | X 6 CrNiMo 17-12-03 | - |
| 316 L | X 2 CrNiMo 17 13 2 | 1.4404 | Z 2 CND 17-12 | SUS 316L | X 2 CrNiMo 1712 | 23 48 | 316S11 | X 3 CrNiMo 17 12 2 | X 2 CrNiMo 17-12-03 | 03KH17N14M2 |
| 317 L | X 2 CrNiMo 18 16 4 | 1.4438 | Z 2 CND 19-15 | SUS 317L | X 2 CrNiMo 1815 | 23 67 | 317S12 | X 3 CrNiMo 18 16 4 | - | - |
| 321 | X 6 CrNiTi 18 10 | 1.4541 | Z 6 CNT 18-10 | SUS 321 | X 6 CrNiTi 1811 | 23 37 | 321S31 | X 6 CrNiTi 18 10 | X 6 CrNiTi 18-11 | 08KH18N10T |
| 904L | - | 1.4939 | Z 12 CNDV 12-02 | - | - | - | - | - | - | - |
| UNS31803 | X 2 CrNiMoN 22 5 | 1.4462 | - | - | - | - | - | - | - | - |
Seamless coiled tubing is the preferred choice in critical applications, as it eliminates the risk of impurities often associated with welded coiled tubing.
With over ten years of experience exporting stainless steel tube products, we operate state-of-the-art production lines capable of producing continuous welded pipe. Utilizing world-class bright annealing technology, we perform online stainless steel pipe softening treatment alongside comprehensive testing: compressed, flaring, bending test, 100% hardness, stretch, and air tightness tests, ensuring reliable quality and industry-standard precision.
Grade 316L is the low carbon version of 316 and is immune from sensitisation (grain boundary carbide precipitation). It offers higher creep, stress to rupture, and tensile strength at elevated temperatures compared to typical chromium-nickel austenitic stainless steels, making it excellent for heavy gauge welded components.
Seamless coiled tubing is the optimal choice for critical applications because it carries zero risk of impurities, which are sometimes associated with welded tubing. It improves system safety, provides higher corrosion resistance, and eliminates the need for joints and fittings, reducing leak potential.
The common outer diameter ranges from 6.52mm to 20mm with wall thicknesses between 0.2mm and 2.0mm. Tolerances are precisely maintained with OD at ±0.1mm, wall thickness at ±10%, and length options from 300 to 3500 meters per coil.
Comprehensive quality control tests are applied, including compression, flaring, bending, 100% hardness, stretch, and air tightness tests, ensuring high tolerance precision and uniform wall thickness.
Stainless steel coiled tubing is widely used in refrigeration equipment, evaporators, gas-liquid delivery systems, condensers, beverage machines, petrochemical plants, CNG piping, boilers, desalination facilities, and geothermal plants.
