Wholesale 304 Stainless steel capillary tube Manufacturer, Pricelist

Products name :Stainless steel capillary tube Grade :201 304 304L 316 316L 904L 310s 2205 2507 625 825 Usage :Dynamic instrument signal tube, automatic instrument wire protection tube; Precision optical ruler line, industrial sensors, electronic equipment line protection tube; The safety protection of electrical circuit, the protection of thermal instrument capillaries and the inner support of hollow core high voltage cable Size :OD:0.25-28mm Thinkness:0.08-1.5mm Surface : bright and soft Annealed Stype: stright or coiled , Length: 600-3500M/coil without welded joint Advantage: We are a manufacturer . Lowest Price and Good Quantity Guarantee&Inspection : Chemical composition and physical properties,Eddy Current Test,Hydro Test

Send Inquiry

Product Description

Stainless Steel Capillary Tube Specifications

Product Name

Stainless steel capillary tube

Available Grades

201, 304, 304L, 316, 316L, 904L, 310s, 2205, 2507, 625, 825

Size Range

OD: 0.25 - 28mm | Thickness: 0.08 - 1.5mm

Surface & Style

Bright and soft Annealed | Straight or Coiled

Coil Length

600 - 3500M/coil without welded joint

Inspection & Test

Chemical & physical check, Eddy Current, Hydro Test

Primary Applications & Usages:

Dynamic instrument signal tubes and automatic instrument wire protection tubes.
Precision optical ruler lines, industrial sensors, and electronic equipment line protection tubing.
Safety protection of electrical circuits and protection of thermal instrument capillaries.
Inner support systems for hollow core high voltage cables.

304 Stainless Steel Capillary Tube Size Chart

Stainless Steel capillary tubing (Grade: 316L, 304, 304L, 2205, 904L, 2507, 625, 825 \| MOQ: 500kgs)
0.25*0.08	1.4*0.4	2.3*0.2	3.2*0.25	4.5*0.7	6*0.45	8*0.3	11*0.5	0.8*0.2	10*1
0.3*0.1	1.5*0.1	2.3*0.25	3.2*0.3	4.5*0.75	6*0.5	8*0.4	11*1	0.85*0.175	12*0.5
0.4*0.1	1.5*0.125	2.3*0.3	3.2*0.35	4.5*0.8	6*0.6	8*0.45	11*1.5	1.1*0.2	12*1
0.5*0.1	1.5*0.15	2.4*0.15	3.2*0.4	4.5*0.9	6*0.7	8*0.5	11*2	1.1*0.3	12*1.5
0.5*0.125	1.5*0.2	2.4*0.2	3.2*0.5	4.5*1	6*0.8	8*0.6	11.1*0.4	1.2*0.135	12*2.0
0.5*0.15	1.5*0.25	2.4*0.25	3.2*0.6	4.7*0.2	6*0.9	8*0.7	12*0.2	1.6*0.25	12.8*1.6
0.6*0.1	1.5*0.3	2.4*0.3	3.2*0.8	4.7*0.25	6*1.0	8*0.8	12*0.25	1.9*0.1	14*0.5
0.6*0.125	1.5*0.35	2.4*0.4	3.4*0.5	4.7*0.3	6*1.2	8*0.9	12*0.3	2*0.3	14*1.5
0.6*0.15	1.5*0.4	2.4*0.5	3.5*0.15	4.8*0.125	6*1.25	8*1	12*0.4	2*0.4	14*2.0
0.63*0.15	1.5*0.45	2.4*0.6	3.5*0.2	4.8*0.2	6*1.5	8*1.2	12*0.5	2*0.5	15*0.5
0.7*0.1	1.5*0.5	2.4*0.7	3.5*0.25	4.8*0.25	6*2	8*1.5	12*1	2*0.6	15*1.5
0.7*0.125	1.6*0.1	2.4*0.75	3.5*0.3	4.8*0.3	6.35*0.3	8*2	12.3*0.4	2.5*0.25	15*2
0.7*0.15	1.6*0.125	2.4*0.8	3.5*0.4	4.8*0.5	6.35*0.5	8*2.5	12.7*0.3	2.5*0.3	16*0.5
0.7*0.2	1.6*0.15	2.5*0.1	3.5*0.5	5*0.1	6.35*0.7	8.5*0.2	13*0.5	2.5*0.5	16*1.0
0.8*0.1	1.6*0.2	2.5*0.15	3.5*0.55	5*0.15	6.35*1.0	8.5*0.25	13*1	3*0.5	16*1.5
0.8*0.125	1.6*0.25	2.5*0.2	3.5*0.7	5*0.2	6.4*0.225	8.5*0.3	13*1.5	3*0.8	16*2.0
0.8*0.15	1.6*0.3	2.5*0.25	3.5*0.8	5*0.25	6.5*0.2	8.5*0.4	13*2	3*1	17*1.5
0.8*0.2	1.6*0.35	2.5*0.3	3.5*1.0	5*0.3	6.5*0.25	8.5*0.5	13.5*0.5	4*0.3	17*2.0
0.8*0.25	1.6*0.4	2.5*0.35	3.5*1.15	5*0.35	6.5*0.3	8.5*1.0	14*0.25	4*0.5	18*1.5
0.9*0.1	1.65*0.3	2.5*0.4	3.6*0.15	5*0.4	6.5*0.4	8.5*1.3	14*0.3	4*1	18*2.0
0.9*0.15	1.7*0.1	2.5*0.45	3.7*0.15	5*0.45	6.5*0.5	8.5*1.5	14*0.5	4.8*0.15	19*1.5
0.9*0.2	1.7*0.15	2.5*0.5	3.7*0.2	5*0.5	6.5*0.6	8.9*1.4	14*1	5*0.5	19*2.0
0.9*0.25	1.7*0.2	2.5*0.6	3.7*0.5	5*0.6	6.5*0.7	9*0.2	14.2*0.2	5*1	20*1.0
1.0*0.1	1.7*0.25	2.5*0.65	3.8*0.2	5*0.7	6.5*0.8	9*0.25	15*0.3	5.5*1.75	20*1.5
1.0*0.125	1.7*0.3	2.5*0.7	3.8*0.25	5*0.75	6.5*0.9	9*0.3	15*0.5	6*0.15	20*2.0
1.0*0.15	1.8*0.1	2.5*0.85	3.8*0.3	5*0.8	6.5*1	9*0.4	15*1	6*0.25	20*2.5
1.0*0.2	1.8*0.15	2.6*0.15	3.9*0.2	5*0.9	6.5*1.3	9*0.5	16*0.5	6*0.3	21*1.0
1.0*0.25	1.8*0.2	2.6*0.2	4*0.1	5*1.0	6.7*0.5	9*0.6	16*1	6*0.5	22*1.5
1.0*0.3	1.8*0.25	2.6*0.3	4*0.15	5*1.2	6.8*0.15	9*0.7	17*0.5	6*0.85	25*1.5
1.0*0.35	1.8*0.3	2.6*0.5	4*0.2	5*1.5	7*0.15	9*0.8	17*1	6*1	28.6*1.5
1.1*0.1	1.8*0.35	2.65*0.15	4*0.25	5.2*0.2	7*0.2	9*0.9	18*0.5	7*0.3
1.1*0.12	1.8*0.4	2.7*0.15	4*0.3	5.2*0.3	7*0.25	9*1	18*1.0	7*0.5
1.1*0.125	1.9*0.1	2.7*0.2	4*0.35	5.2*0.45	7*0.3	9*1.5	19*0.5	7*1.0
1.1*0.15	1.9*0.15	2.7*0.3	4*0.4	5.2*0.5	7*0.35	9*2	19*1.0	8*0.5
1.1*0.2	1.9*0.2	2.8*0.15	4*0.45	5.4*0.2	7*0.4	9.5*0.25	20*0.5	8*1
1.1*0.25	1.9*0.25	2.8*0.2	4*0.5	5.45*0.275	7*0.45	9.5*0.3	21*0.5	9*0.5
1.2*0.1	2*0.1	2.8*0.25	4*0.6	5.5*0.15	7*0.5	9.5*0.5		9*1
1.2*0.12	2*0.125	2.8*0.3	4*0.7	5.5*0.2	7*0.6	9.5*0.7		10*0.5
1.2*0.125	2*0.15	2.8*0.5	4*0.75	5.5*0.25	7*0.7	9.5*1		10*1
1.2*0.15	2*0.2	2.8*0.7	4*0.8	5.5*0.3	7*0.8	9.5*1.5
1.2*0.2	2*0.25	2.9*0.3	4*0.9	5.5*0.4	7*0.9	10*0.2
1.2*0.25	2*0.3	3*0.1	4*1.0	5.5*0.5	7*1.0	10*0.25
1.2*0.3	2*0.35	3*0.15	4*1.25	5.5*0.6	7*1.2	10*0.3
1.2*0.4	2*0.4	3*0.2	4*1.5	5.5*0.7	7*1.5	10*0.4
1.3*0.1	2*0.45	3*0.25	4.2*0.2	5.5*0.75	7*2	10*0.5
1.3*0.12	2*0.5	3*0.3	4.2*0.25	5.5*0.8	7.5*0.2	10*0.6
1.3*0.125	2*0.6	3*0.35	4.2*0.3	5.5*1	7.5*0.25	10*0.7
1.3*0.135	2*0.7	3*0.4	4.2*0.4	5.6*0.85	7.5*0.3	10*0.8
1.3*0.15	2.1*0.15	3*0.5	4.2*0.5	5.7*0.2	7.5*0.4	10*0.9
1.3*0.175	2.1*0.2	3*0.6	4.3*0.9	5.7*0.3	7.5*0.5	10*1.0
1.3*0.2	2.1*0.25	3*0.7	4.4*0.45	5.8*0.15	7.5*0.6	10*1.5
1.3*0.25	2.1*0.65	3*0.75	4.4*0.5	5.8*0.2	7.5*0.7	10*2
1.3*0.3	2.2*0.15	3*0.8	4.5*0.15	5.8*0.5	7.5*0.8	10*2.5
1.4*0.1	2.2*0.2	3*0.9	4.5*0.2	5.8*0.7	7.5*0.9	10.3*0.2
1.4*0.15	2.2*0.25	3*1.0	4.5*0.25	6*0.15	7.5*1.0	10.8*0.2			soft bright
1.4*0.2	2.2*0.3	3*1.1	4.5*0.3	6*0.2	7.8*0.5	11*0.2			1.5*0.15
1.4*0.25	2.2*0.5	3*1.2	4.5*0.4	6*0.25	8*0.15	11*0.25			2*0.5
1.4*0.3	2.3*0.125	3.2*0.15	4.5*0.5	6*0.3	8*0.2	11*0.3			2.5*0.5
1.4*0.35	2.3*0.15	3.2*0.2	4.5*0.6	6*0.4	8*0.25	11*0.4			5*0.5

Our Advantage

Capillary tube quality control standards

Product Display

Stainless Steel Grades

American Standard: TP304, TP304L, TP304H, TP321, TP321H, TP316L, TP316SS, TP316Ti, TP347, TP347H, TP317L, TP309S, TP310S, 904L

Russian Standard: 08X18H10, 03X18H11, 10X17H13M2T, 03X17H13M2, 12X18H10T, 08X18H10T, 08X18H12B

German Standard: 1.4301, 1.4306, 1.4541, 1.4404, 1.4571, 1.4550

Japanese Standard: SUS304, SUS304L, SUS321, SUS316L, SUS316Ti, SUS347, SUS800, SUS840

Double-Grade: 304/304L, 316/316L, 321/321H, 347/347H

Super Duplex Steel: 2205, 2304, S31803, S32750

Nickel Alloys: Inconel 600, Inconel 601, Inconel 625, Inconel 725, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926, etc.

SS316L Capillary Tubing Specifications and Pressure Rating

Stainless Steel Capillary Tubing Chemical Composition

Grades	UNS	C	Mn	P	S	Si	Cr	Ni	Mo	Ti	Nb	N
TP304	S30400	0.08	2	0.045	0.03	1	18.0-20.0	8.0-11.0	-	-	-	-
TP304L	S30403	0.035	2	0.045	0.03	1	18.0-20.0	8.0-13.0	-	-	-	-
TP316	S31600	0.08	2	0.045	0.03	1	16.0-18.0	11.0-14.0	2.0-3.0	-	-	-
TP316L	S31603	0.035	2	0.045	0.03	1	16.0-18.0	10.0-14.0	2.0-3.0	-	-	-

Stainless Steel Capillary Tubing Mechanical Properties

Material	Heat Treatment	Temperature Min. ºF(ºC)	Tensile Strength Ksi (MPa), Min.	Yield Strength Ksi (MPa), Min.	Elongation % Min
TP304	Solution	1900 (1040)	75 (515)	30 (205)	35
TP304L	Solution	1900 (1040)	70 (485)	25 (170)	35
TP316	Solution	1900 (1040)	75 (515)	30 (205)	35
TP316L	Solution	1900 (1040)	70 (485)	25 (170)	35

Stainless Steel Capillary Tubing Equivalent Grades

Grade Name	UNS NO	DIN/WERKSTOFF
Stainless Steel Capillary Tube 304	S30400	1.4301
Stainless Steel Capillary Tube 304L	S30403	1.4306
Stainless Steel Capillary Tube 316	S31600	1.4436
Stainless Steel Capillary Tube 316L	S31603	1.4404

Related Search Categories:

304 capillary tube 316L grade Downhole Chemical Injection Tubing Stainless steel Capillary Pipe trader stainless steel Capillary Pipe astm stainless steel capillary tubing cutter hplc stainless steel capillary tubing cutting stainless steel capillary tubing stainless steel 1/16 in. capillary tubing weight of stainless steel Capillary pipe per foot stainless steel Capillary pipe for sale Stainless Steel Capillary pipe Suppliers stainless steel Capillary tubing grades stainless steel Capillary pipe hs code stainless steel Capillary tubing metric stainless steel Capillary tubing properties stainless steel Capillary Tube supplier in china exporter of stainless steel Capillary pipe 304 stainless steel Capillary Tube manufacturer in china ss seamless Capillary Tube stockholder in China seamless Capillary Pipe exporter

Frequently Asked Questions (FAQ)

What size ranges are available for stainless steel capillary tubes?

Our capillary tubing is available in outer diameters (OD) ranging from 0.25mm up to 28mm, and wall thicknesses from 0.08mm up to 1.5mm. We can accommodate custom sizing requirements within this range.

Which stainless steel grades do you supply?

We supply a comprehensive list of grades, including standard grades like 201, 304, 304L, 316, and 316L. We also provide specialty and high-alloy grades such as 904L, 310s, duplex 2205, super duplex 2507, and nickel alloys like Inconel 625 and Incoloy 825.

Can capillary tubes be supplied in long continuous coils?

Yes, we specialize in manufacturing long continuous coils without any welded joints, with lengths ranging from 600 to 3500 meters per coil. We also supply straight cut-to-length tubes depending on your application requirements.

What types of testing and quality inspections are performed?

To guarantee the highest quality and safety, all our capillary tubes undergo strict inspections, including Chemical Composition verification, Physical Properties analysis, Eddy Current Testing, and Hydrostatic (Hydro) Testing.

What are the primary applications of stainless steel capillary tubes?

Capillary tubes are widely used for dynamic instrument signal transmission, automatic instrument wire protection, precision optical rulers, industrial sensors, electronic equipment protection, thermal instrument capillary systems, and inner support structures for high-voltage cables.

What surface finish is provided on the tubes?

Our stainless steel capillary tubes are supplied with a bright and soft annealed surface finish, which ensures optimal flexibility, smooth inner/outer surfaces, and excellent corrosion resistance.
