China 304 Stainless Steel Capillary Tubing Supplier and Manufacturer for Global B2B Buyers

Products Description: 304 grade Stainless Steel Coiled Tube, 304 stainless steel capillary Coiled Tube, 304 Hydraulic Control Line, Duplex 2205 Coiled tubing Control Line, Monel400, Inconel 825 Coiled tubing Control Line. Stainless steel Control Line, stainless steel bening tube, Steel rolled pipe.bending stainless steel tubing into coil,

Related Grades & Standards

Common Grade

TP304, TP304L, TP304H
TP321, TP321H
TP316L, TP316SS, TP316Ti
TP347, TP347H, TP317L
TP309S, TP310S, 904L

Russian Standard

08X18H10, 03X18H11
10X17H13M2T, 03X17H13M2
12X18H10T, 08X18H10T, 08X18H12B

German Standard

1.4301, 1.4306
1.4541, 1.4404
1.4571, 1.4550

Japanese Standard

SUS304, SUS304L
SUS321, SUS316L, SUS316Ti
SUS347, SUS800, SUS840

Double-Grade & Duplex

Double: 304/304L, 316/316L
Double: 321/321H, 347/347H
Super Duplex: 2205, 2304, S31803, S32750

Inconel & Incoloy

Inconel 600, Inconel 601, Inconel 625, Inconel 725
Incoloy 800, Incoloy 800H, Incoloy 800HT
Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926

Pressure and Length Standards

Seamless Stainless Steel Coiled Tubing Control Line Common Size
ITEM	Material Grade	Size (mm)	Length (Mtrs)	Pressure (Mpa)
1	304L 304 316 316L 904l 310s 625 825 2205 2507 Stainless Steel Capillary Tube	1/8″×0.025″	3200	80
2	304L 304 316 316L 904l 310s 625 825 2205 2507 Stainless Steel Capillary Tube	1/8″×0.035″	3200	100
3	304L 304 316 316L 904l 310s 625 825 2205 2507 Stainless Steel Capillary Tube	1/4″×0.035″	2000	100
4	304L 304 316 316L 904l 310s 625 825 2205 2507 Stainless Steel Capillary Tube	1/4″×0.049″	2000	100
5	304L 304 316 316L 904l 310s 625 825 2205 2507 Stainless Steel Capillary Tube	3/8″×0.035″	1500	80
6	304L 304 316 316L 904l 310s 625 825 2205 2507	3/8″×0.049″	1500	100
7	304L 304 316 316L 904l 310s 625 825 2205 2507	1/2″×0.049″	1000	80
8	304L 304 316 316L 904l 310s 625 825 2205 2507	1/2″×0.065″	1000	100
9	304L 304 316 316L 904l 310s 625 825 2205 2507	φ3mm×0.7mm	3200	80
10	304L 304 316 316L 904l 310s 625 825 2205 2507	φ3mm×0.9mm	3200	100
11	304L 304 316 316L 904l 310s 625 825 2205 2507	φ4mm×0.9mm	3000	100
12	304L 304 316 316L 904l 310s 625 825 2205 2507	φ4mm×1.1mm	3000	100
13	304L 304 316 316L 904l 310s 625 825 2205 2507	φ6mm×0.9mm	2000	100
14	304L 304 316 316L 904l 310s 625 825 2205 2507	φ6mm×1.1mm	2000	100
15	304L 304 316 316L 904l 310s 625 825 2205 2507	φ8mm×1mm	1800	80
16	304L 304 316 316L 904l 310s 625 825 2205 2507	φ8mm×1.2mm	1800	100
17	304L 304 316 316L 904l 310s 625 825 2205 2507	φ10mm×1mm	1500	70
18	304L 304 316 316L 904l 310s 625 825 2205 2507	φ10mm×1.2mm	1500	70
19	304L 304 316 316L 904l 310s 625 825 2205 2507	φ10mm×2mm	500	100
20	304L 304 316 316L 904l 310s 625 825 2205 2507	φ12mm×1.5mm	500	80

Control Line Product Specifications

Thickness	0.1 to 2mm
Material Grade	304, 304L, 316, 316L, 321, 316Ti, 904L, Duplex 2205, Monel400, Inconel 625, Inconel 825
Diameter	1.5 to 15 mm OD, 1/4 inch, 3/8 inch in stock. Common sizes in stock: 6.35mm1.24mm, 80.5mm, 80.8mm, 60.89mm, 81mm, 9.531.24mm, 10*1mm, etc.
Shape	Round
Unit Pipe Length	Production of at least 8,000 feet - 10,000 feet/coil. Customized lengths available.
Range	All sizes and lengths available
Size	As per the requirement
Surface	Bright annealed, Polished soft inner and outer in clean condition
Pipe Fluid	Chemical, Water, Gas, Oil
Minimum Order Quantity	500 kgs

Related Applications & Uses

1

Medical Acupuncture with Coiled Tubing Control Line
2

High-pressure instrumentation with Coiled Tubing Control Line
3

Coal exploration with a stainless steel Control Line
4

Thermostat with Control Line
5

Beer machine with stainless steel Control Line
6

Drinking water equipment with stainless steel Control Line
7

Danfoss expansion valve with stainless steel Coiled Tubing Control Line

Specifications: Outer diameter: 0.3mm - 10mm | Tolerance: 0.005mm - 0.01mm

Stainless Steel Capillary Tube Size Specifications (304 / 316L)

0.25*0.08

1.4*0.4

2.3*0.2

3.2*0.25

4.5+0.7

6*0.45

8*0.3

11*0.5

0.8*0.2

10*1

0.3*0.1

1.5*0.1

2.3*0.25

3.2*0.3

4.5*0.75

6*0.5

8*0.4

11*1

0.85*0.175

12*0.5

0.4*0.1

1.5*0.125

2.3*0.3

3.2*0.35

4.5*0.8

6*0.6

8*0.45

11*1.5

1.1*0.2

12*1

0.5*0.1

1.5*0.15

2.4*0.15

3.2*0.4

4.5*0.9

6*0.7

8*0.5

11*2

1.1*0.3

12*1.5

0.5*0.125

1.5*0.2

2.4*0.2

3.2*0.5

4.5*1

6*0.8

8*0.6

11.1*0.4

1.2*0.135

12*2.0

0.5*0.15

1.5*0.25

2.4*0.25

3.2*0.6

4.7*0.2

6+0.9

8*0.7

12*0.2

1.6*0.25

12.8*1.6

0.6*0.1

1.5*0.3

2.4*0.3

3.2*0.8

4.7*0.25

6*1.0

8*0.8

12*0.25

1.9*0.1

14*0.5

0.6*0.125

1.5+0.35

2.4*0.4

3.4*0.5

4.7*0.3

6*1.2

8*0.9

12*0.3

2*0.3

14+1.5

0.6*0.15

1.5*0.4

2.4*0.5

3.5*0.15

4.8*0.125

6*1.25

8*1

12*0.4

2*0.4

14*2.0

0.63*0.15

1.5+0.45

2.4*0.6

3.5+0.2

4.8*0.2

6*1.5

8*1.2

12*0.5

2*0.5

15+0.5

0.7*0.1

1.5*0.5

2.4*0.7

3.5*0.25

4.8*0.25

6*2

8*1.5

12*1

2*0.6

15*1.5

0.7*0.125

1.6*0.1

2.4*0.75

3.5*0.3

4.8*0.3

6.35*0.3

8*2

12.3*0.4

2.5*0.25

15*2

0.7*0.15

1.6*0.125

2.4*0.8

3.5*0.4

4.8*0.5

6.35*0.5

8*2.5

12.7*0.3

2.5*0.3

16*0.5

0.7*0.2

1.6*0.15

2.5*0.1

3.5*0.5

5*0.1

6.35*0.7

8.5*0.2

13*0.5

2.5*0.5

16*1.0

0.8*0.1

1.6*0.2

2.5*0.15

3.5+0.55

5+0.15

6.35*1.0

8.5*0.25

13*1

3*0.5

16*1.5

0.8*0.125

1.6*0.25

2.5*0.2

3.5*0.7

5*0.2

6.4*0.225

8.5*0.3

13*1.5

3*0.8

16*2.0

0.8*0.15

1.6*0.3

2.5*0.25

3.5*0.8

5+0.25

6.5*0.2

8.5+0.4

13*2

3*1

17*1.5

0.8*0.2

1.6*0.35

2.5*0.3

3.5*1.0

5*0.3

6.5*0.25

8.5*0.5

13.5*0.5

4*0.3

17*2.0

0.8*0.25

1.6*0.4

2.5*0.35

3.5*1.15

5*0.35

6.5*0.3

8.5*1.0

14*0.25

4*0.5

18*1.5

0.9*0.1

1.65*0.3

2.5*0.4

3.6*0.15

5*0.4

6.5*0.4

8.5*1.3

14*0.3

4*1

18*2.0

0.9*0.15

1.7*0.1

2.5*0.45

3.7*0.15

5+0.45

6.5+0.5

8.5*1.5

14*0.5

4.8*0.15

19*1.5

0.9*0.2

1.7*0.15

2.5*0.5

3.7*0.2

5*0.5

6.5*0.6

8.9*1.4

14*1

5*0.5

19*2.0

0.9*0.25

1.7*0.2

2.5*0.6

3.7*0.5

5*0.6

6.5*0.7

9*0.2

14.2*0.2

5*1

20*1.0

1.0*0.1

1.7*0.25

2.5*0.65

3.8*0.2

5*0.7

6.5*0.8

9*0.25

15*0.3

5.5*1.75

20*1.5

1.0*0.125

1.7*0.3

2.5*0.7

3.8*0.25

5*0.75

6.5*0.9

9*0.3

15*0.5

6*0.15

20*2.0

1.0+0.15

1.8*0.1

2.5*0.85

3.8+0.3

5*0.8

6.5*1

9*0.4

15*1

6*0.25

20*2.5

1.0*0.2

1.8*0.15

2.6*0.15

3.9*0.2

5*0.9

6.5*1.3

9*0.5

16*0.5

6*0.3

21*1.0

1.0*0.25

1.8*0.2

2.6+0.2

4+0.1

5*1.0

6.7*0.5

9*0.6

16*1

6*0.5

22*1.5

1.0*0.3

1.8*0.25

2.6*0.3

4*0.15

5*1.2

6.8*0.15

9*0.7

17*0.5

6*0.85

25*1.5

1.0*0.35

1.8*0.3

2.6*0.5

4*0.2

5*1.5

7*0.15

9*0.8

17*1

6*1

28.6*1.5

1.1*0.1

1.8*0.35

2.65*0.15

4*0.25

5.2*0.2

7*0.2

9*0.9

18*0.5

7*0.3

1.1*0.12

1.8*0.4

2.7+0.15

4+0.3

5.2*0.3

7*0.25

9*1

18*1.0

7*0.5

1.1*0.125

1.9*0.1

2.7*0.2

4*0.35

5.2*0.45

7*0.3

9.5*0.25

19*0.5

7*1.0

1.1*0.15

1.9*0.15

2.7*0.3

4*0.4

5.2*0.5

7*0.35

9*2

19*1.0

8*0.5

1.1*0.2

1.9*0.2

2.8*0.15

4*0.45

5.4*0.2

7*0.4

9.5*0.25

20*0.5

8*1

1.1*0.25

1.9*0.25

2.8*0.2

4*0.5

5.45*0.275

7*0.45

9.5*0.3

21*0.5

9*0.5

1.2*0.1

2*0.1

2.8*0.25

4*0.6

5.5*0.15

7*0.5

9.5*0.5

9*1

10*0.5

1.2*0.12

2*0.125

2.8*0.3

4*0.7

5.5*0.2

7*0.6

9.5*0.7

10*1

1.2*0.125

2*0.15

2.8+0.5

4*0.75

5.5*0.25

7*0.7

9.5*1

1.2*0.15

2*0.2

2.8*0.7

4*0.8

5.5*0.3

7*0.8

9.5*1.5

1.2*0.2

2*0.25

2.9+0.3

4+0.9

5.5*0.4

7*0.9

10*0.2

1.2*0.25

2*0.3

3*0.1

4*1.0

5.5*0.5

7*1.0

10*0.25

1.2*0.3

2*0.35

3*0.15

4*1.25

5.5*0.6

7*1.2

10*0.3

1.2*0.4

2*0.4

3*0.2

4*1.5

5.5*0.7

7*1.5

10*0.4

1.3*0.1

2*0.4S

3*0.25

4.2*0.2

5.5*0.75

7*2

10*0.5

1.3*0.12

2*0.5

3*0.3

4.2*0.25

5.5*0.8

7.5*0.2

10*0.6

1.3*0.125

2*0.6

3*0.35

4.2*0.3

5.5*1

7.5*0.25

10*0.7

1.3*0.135

2*0.7

3*0.4

4.2*0.4

5.6*0.85

7.5*0.3

10*0.8

1.3*0.15

2.1*0.15

3*0.5

4.2*0.5

5.7*0.2

7.5*0.4

10*0.9

1.3+0.175

2.1*0.2

3*0.6

4.3*0.9

5.7*0.3

7.5*0.5

10*1.0

1.3*0.2

2.1*0.25

3*0.7

4.4*0.45

5.8*0.15

7.5*0.6

10*1.5

1.3*0.25

2.1*0.65

3*0.75

4.4*0.5

5.8*0.2

7.5+0.7

10*2

1.3*0.3

2.2*0.15

3*0.8

4.5*0.15

5.8*0.5

7.5*0.8

10*2.5

1.4*0.1

2.2*0.2

3*0.9

4.5*0.2

5.8*0.7

7.5*0.9

10.3*0.2

1.4*0.15

2.2*0.25

3*1.0

4.5*0.25

6*0.15

7.5*1.0

10.8*0.2

soft

1.4*0.2

2.2*0.3

3*1.1

4.5+0.3

6*0.2

7.8*0.5

11*0.2

1.5*0.15

1.4*0.25

2.2*0.5

3*1.2

4.5*0.4

6*0.25

8*0.15

11*0.25

2*0.5

1.4*0.3

2.3*0.125

3.2*0.15

4.5*0.5

6*0.3

8*0.2

11*0.3

2.5*0.5

1.4*0.35

2.3*0.15

3.2*0.2

4.5*0.6

6*0.4

8*0.25

11*0.4

5*0.5

Frequently Asked Questions (FAQ)

What grades of stainless steel coiled tubing do you offer?

We provide a wide variety of grades including Common Grades (TP304, TP304L, TP316L, 904L, etc.), Russian standards (08X18H10, etc.), German standards (1.4301, 1.4404, etc.), Japanese standards (SUS304, SUS316L, etc.), Double-Grades, and Super Duplex Steel (2205, 2304, S31803, S32750), alongside High Nickel alloys like Monel400, Inconel 625, and Inconel 825.

What is the typical unit length of the coiled tubing?

We can manufacture seamless control lines with lengths of at least 8,000 to 10,000 feet per coil. Custom lengths can also be tailored to meet your specific application requirements.

What are the pressure ratings and size ranges for these tubes?

Our standard size range covers outer diameters (OD) from 1.5 mm to 15 mm (including 1/8", 1/4", 3/8", and 1/2" options). Depending on the wall thickness and size, they are rated to withstand working pressures from 70 Mpa up to 100 Mpa.

What surface treatment options are available for the capillary tubes?

Our tubes come with a bright annealed finish. They are polished soft on both the inner and outer surfaces to maintain high cleanliness for fluid control systems.

What are the main applications of these control lines?

These coiled tubes are widely used in medical acupuncture, high-pressure instrumentation, coal exploration, thermostats, beer brewing equipment, drinking water systems, and refrigeration systems using Danfoss expansion valves.

What is the Minimum Order Quantity (MOQ) for coiled control lines?

The minimum order quantity for our production runs of stainless steel coiled tubing is 500 kilograms per specification.
