China Stainless Steel Sheet and Coil - Type 410 Product Suppliers, Pricelist

1. Type: Stainless Steel coil Sheet 2. Specification: TH 0.3-70mm, width 600-2000mm 3. Standard: ASTM, AISI, JIS, DIN, GB 4. Technique: Cold rolled or hot rolled 5. Surface Treatment: 2b, Ba, Hl, No.1, No.4, Mirror, 8k Golden or as requirement 6. Certificates: Mill Test Certificate, ISO,SGS or Other Third Party in 7. Application: Construction, Machine Building, Container etc. 8. Origin: Shanxi/Tisco or Shanghai/Baosteel 9. Package: Standard Export Package 10. Stock : Stock

Send Inquiry

Product Description

Stainless Steel Sheet and Coil - Type 410 Product

Stainless steel sheet & plate is often referred to as corrosion-resistant steel since it does not stain, corrode or rust as easily as regular carbon steel. Stainless steel sheet & plate is the perfect solution for applications that require the metal to have anti-oxidation qualities.

Stainless steel products:

stainless steel coil tube stainless steel tube coil stainless steel coil tubing stainless steel coil pipe stainless steel coil tube suppliers stainless steel coil tube manufacturers stainless steel pipe coil

Product Line Description

Standard Finish

Cold Rolled, Annealed No. 2B Finish

Optional Finishes

• No. 3 Finish - Polished One or Two Sides
• No. 4 Finish - Polished One or Two Sides

Magnetic Properties

Non-Magnetic (May be Slightly magnetic when cold worked)

Interleaving & Standards

• Paper Interleaved or Vinyl Masked: 22 Gauge and Heavier
• A.S.T.M. A240/A480 ASME SA-240
• A.S.T.M. A262 Prac E

410 Stainless Steel Chemical Composition

Grade		C	Mn	Si	P	S	Cr	MO	Ni	N
410	min.	–	–	–	–	–	11.5	–	–	–
410	max.	0.15	1.0	1.0	0.040	0.030	13.5	–	0.75	–

Stainless Steel 410 Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
410	480	275	16	92	201

Stainless Steel 410 Physical Properties

Grade	Density (kg/m³)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
Grade	Density (kg/m³)	Elastic Modulus (GPa)	0-1000C	0-3150C	0-5380C	at 1000C	at 5000C	Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
410	7750	200	9.9	11.4	11.6	24.9	28.7	460	570

Equivalent Grades for 410 Stainless Steel

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 410	1.4006	S41000	SUS 410	–	–	–	–

Applications

Rapid transit cars, buses, aircraft, cargo containers

Retractor springs

Hose clamps

Conveyors

Bottling machinery

Jewelry

Cryogenic vessels and components

Still tubes

Expand metal parts

Mixing bowls

Dryers

Furnace parts

Heat exchangers

Paper mill equipment

Oil refining equipment

Textile industry

Dyeing equipment

Jet engine parts

Welded storage tanks for organic chemicals

Combustion chambers

Furnace arch supports

Kiln linings

Smoke control ductwork

Coal chutes

Gauge parts

Cutlery

Fish hooks

Glass molds

Bank vaults

Fasteners

Skewers

Dairy industry

Burner and emission control components

Recuperators

Pipes, tubes

Features & Specifications

Commodity: stainless steel sheet/Plate

Material: 201, 202, 304, 304L, 316, 316L, 309S, 310S, 317L, 321, 409, 409L, 410, 420, 430, etc

Surface: 2B, BA, HL, 4K, 6K, 8KNO. 1, NO. 2, NO. 3, NO. 4, NO. 5, and so on

Standard: AISI, ASTM, DIN, EN, GB, JIS, etc

Specification: (1) thickness: 0.3mm- 100mm | (2) width: 1000mm, 1250mm, 1500mm, 1800mm, 2000mm, etc | (3) length: 2000mm, 2440mm, 3000mm, 6000mm, etc | (4) Specifications can be provided as clients' requirements.

Application: (1) Construction, decoration | (2) petroleum, chemical industry | (3) electrical appliances, automotive, aerospace | (4) house ware, kitchen appliances, cutlery, foodstuff | (5) surgical instrument

Package: (1) Products are packed and labeled according to regulation | (2) According to customers' requirements

Delivery: within 20 working days since deposit, mainly according to quantity and transportation ways.

Payment: T/T, L/C

Shipment: FOB/CIF/CFR

Productivity: 500tons/month

Note: Other grade products can be supplied as customers' requirements.

Standard & Material Grouping

1. ASTM A240 Standard

201, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316H, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 409, 410, 410S, 430, 904L

2. ASTM A480 Standard

302, s30215, s30452, s30615, 308, 309, 309Cb, 310, 310Cb, S32615, S33228, S38100, 304H, 309H, 310H, 316H, 309HCb, 310HCb, 321H, 347H, 348H, S31060, N08811, N08020, N08367, N08810, N08904, N08926, S31277, S20161, S30600, S30601, S31254, S31266, S32050, S32654, S32053, S31727, S33228, S34565, S35315, S31200, S31803, S32001, S32550, S31260, S32003, S32101, S32205, S32304, S32506, S32520, S32750, S32760, S32900, S32906, S32950, S32974

3. JIS 4304-2005 Standard

SUS301L, SUS301J1, SUS302, SUS304, SUS304L, SUS316/316L, SUS309S, SUS310S, 3SUS21L, SUS347, SUS410L, SUS430, SUS630

4. JIS G4305 Standard

SUS301, SUS301L, SUS301J1, SUS302B, SUS304, SUS304Cu, SUS304L, SUS304N1, SUS304N2, SUS304LN, SUS304J1, SUSJ2, SUS305, SUS309S, SUS310S, SUS312L, SUS315J1, SUS315J2, SUS316, SUS316L, SUS316N, SUS316LN, SUS316Ti, SUS316J1, SUS316J1L, SUS317, SUS317L, SUS317LN, SUS317J1, SUS317J2, SUS836L, SUS890L, SUS321, SUS347, SUSXM7, SUSXM15J1, SUS329J1, SUS329J3L, SUS329J4L, SUS405, SUS410L, SUS429, SUS430, SUS430LX, SUS430J1L, SUS434, SUS436L, SUS436J1L, SUS444, SUS445J1, SUS445J2, SUS447J1, SUSXM27, SUS403, SUS410, SUS410S, SUS420J1, SUS420J2, SUS440A

Surface Treatment Options

Item	Surface Finishing	Surface Finishing Methods	Main Application
NO.1	HR	Heat treatment after hot rolling, pickling, or with treatment	For without the purpose of the surface gloss
NO.2D	Without the SPM	Method of heat treatment after cold rolling, pickling surface roller with wool or eventually a light rolling a matte surface processing	General materials, building materials.
NO.2B	After SPM	Giving No.2 processing materials appropriate method of cold light sheen	General materials, building materials ( most of the goods are processed )
BA	Bright annealed	Bright heat treatment after cold rolling, in order to be more shiny, cold light effect	Automotive parts, home appliances, vehicles, medical equipment, food equipment
NO.3	Shiny, coarse grain processing	The NO.2D or NO.2B processing timber No. 100-120 polishing abrasive grinding belt	Building materials, kitchen supplies
NO.4	After CPL	The NO.2D or NO.2B processing timber No. 150-180 polishing abrasive grinding belt	Building materials, kitchen supplies, vehicles, medical equipment, food equipment
240#	Grinding of fine lines	The NO.2D or NO.2B processing timber 240 polishing abrasive grinding belt	Kitchen appliances
320#	More than 240 lines of grinding	The NO.2D or NO.2B processing timber 320 polishing abrasive grinding belt	Kitchen appliances
400#	Close to BA luster	The MO.2B timber 400 polishing wheel polishing method	Building materials, kitchen utensils
HL(hair lines)	Polishing line having a long continuous processing	In a suitable size ( usually mostly No. 150-240 grit ) abrasive tape for as long as the hair, having a continuous processing method of polishing line	The most common building materials processing
NO.6	NO.4 processing less than the reflection, the extinction	NO.4 processing material used for polishing Tampico brushing	Building materials, decorative
NO.7	Highly accurate reflectance mirror processing	No. 600 of the rotary buff with a polishing	Building materials, decorative
NO.8	Highest reflectivity mirror finish	Fine particles of abrasive material in order polishing, mirror polishing with a polishing	Building materials, decorative, mirrors

International Grades Comparison

U.S.A.	GERMANY	GERMANY	FRANCE	JAPAN	ITALY	SWEDEN	U.K.	E.U.	SPAIN	RUSSIA
AISI	DIN 17006	W.N. 17007	AFNOR	JIS	UNI	SIS	BSI	EURONORM	UNE	GOST
201	-	-	-	SUS 201	-	-	-	-	-	-
301	X 12 CrNi 17 7	1.431	Z 12 CN 17-07	SUS 301	X 12 CrNi 1707	23 31	301S21	X 12 CrNi 17 7	X 12 CrNi 17-07	-
302	X 5 CrNi 18 7	1.4319	Z 10 CN 18-09	SUS 302	X 10 CrNi 1809	23 31	302S25	X 10 CrNi 18 9	X 10 CrNi 18-09	12KH18N9
303	X 10 CrNiS 18 9	1.4305	Z 10 CNF 18-09	SUS 303	X 10 CrNiS 1809	23 46	303S21	X 10 CrNiS 18 9	X 10 CrNiS 18-09	-
303 Se	-	-	Z 10 CNF 18-09	SUS 303 Se	X 10 CrNiS 1809	-	303S41	-	X 10 CrNiS 18-09	12KH18N10E
304	X 5 CrNi 18 10	1.4301	Z 6 CN 18-09	SUS 304	X 5 CrNi 1810	23 32	304S15	X 6 CrNi 18 10	X 6 CrNi 19-10	08KH18N10
304	X 5 CrNi 18 12	1.4303	Z 6 CN 18-09	SUS 304	X 5 CrNi 1810	23 32	304S16	X 6 CrNi 18 10	X 6 CrNi 19-10	06KH18N11
304 N	-	-	-	SUS 304N1	X 5 CrNiN 1810	-	-	-	-	-
304 H	-	-	-	SUS F 304H	X 8 CrNi 1910	-	-	-	X 6 CrNi 19-10	-
304 L	X 2 CrNi 18 11	1.4306	Z 2 CN 18-10	SUS 304L	X 2 CrNi 1911	23 52	304S11	X 3 CrNi 18 10	X 2 CrNi 19-10	03KH18N11
-	X 2 CrNiN 18 10	1.4311	Z 2 CN 18-10-Az	SUS 304LN	X 2 CrNiN 1811	23 71	-	-	-	-
305	-	-	Z 8 CN 18-12	SUS 305	X 8 CrNi 1812	23 33	305S19	X 8 CrNi 18 12	X 8 CrNi 18-12	-
-	-	-	Z 6 CNU 18-10	SUS XM7	-	-	-	X 6 CrNiCu 18 10 4 Kd	-	-
309	X 15 CrNiS 20 12	1.4828	Z 15 CN 24-13	SUH 309	X 16 CrNi 2314	-	309S24	X 15 CrNi 23 13	-	-
309 S	-	-	-	SUS 309S	X 6 CrNi 2314	-	-	X 6 CrNi 22 13	-	-
310	X 12 CrNi 25 21	1.4845	-	SUH 310	X 22 CrNi 2520	-	310S24	-	-	20KH23N18
310 S	X 12 CrNi 25 20	1.4842	Z 12 CN 25-20	SUS 310S	X 5 CrNi 2520	23 61	-	X 6 CrNi 25 20	-	10KH23N18
314	X 15 CrNiSi 25 20	1.4841	Z 12 CNS 25-20	-	X 16 CrNiSi 2520	-	-	X 15 CrNiSi 25 20	-	20KH25N20S2
316	X 5 CrNiMo 17 12 2	1.4401	Z 6 CND 17-11	SUS 316	X 5 CrNiMo 1712	23 47	316S31	X 6 CrNiMo 17 12 2	X 6 CrNiMo 17-12-03	-
316	X 5 CrNiMo 17 13 3	1.4436	Z 6 CND 17-12	SUS 316	X 5 CrNiMo 1713	23 43	316S33	X 6 CrNiMo 17 13 3	X 6 CrNiMo 17-12-03	-
316 F	X 12 CrNiMoS 18 11	1.4427	-	-	-	-	-	-	-	-
316 N	-	-	-	SUS 316N	-	-	-	-	-	-
316 H	-	-	-	SUS F 316H	X 8 CrNiMo 1712	-	-	-	X 5 CrNiMo 17-12	-
316 H	-	-	-	-	X 8 CrNiMo 1713	-	-	-	X 6 CrNiMo 17-12-03	-
316 L	X 2 CrNiMo 17 13 2	1.4404	Z 2 CND 17-12	SUS 316L	X 2 CrNiMo 1712	23 48	316S11	X 3 CrNiMo 17 12 2	X 2 CrNiMo 17-12-03	03KH17N14M2
-	-	-	-	-	-	-	-	-	-	-
-	X 2 CrNiMoN 17 12 2	1.4406	Z 2 CND 17-12-Az	SUS 316LN	X 2 CrNiMoN 1712	-	-	-	-	-
316 L	X 2 CrNiMo 18 14 3	1.4435	Z 2 CND 17-13	-	X 2 CrNiMo 1713	23 53	316S13	X 3 CrNiMo 17 13 3	X 2 CrNiMo 17-12-03	03KH16N15M3
-	X 2 CrNiMoN 17 13 3	1.4429	Z 2 CND 17-13-Az	-	X 2 CrNiMoN 1713	23 75	-	-	-	-
-	X 6 CrNiMoTi 17 12 2	1.4571	Z6 CNDT 17-12	-	X 6 CrNiMoTi 1712	23 50	320S31	X 6 CrNiMoTi 17 12 2	X 6 CrNiMoTi 17-12-03	08KH17N13M2T
-	X 6 CrNiMoTi 17 12 2	1.4571	Z6 CNDT 17-12	-	X 6 CrNiMoTi 1712	23 50	320S31	X 6 CrNiMoTi 17 12 2	X 6 CrNiMoTi 17-12-03	10KH17N13M2T
-	X 10 CrNiMoTi 18 12	1.4573	-	-	X 6 CrNiMoTi 1713	-	320S33	X 6 CrNiMoTI 17 13 3	X 6 CrNiMoTi 17-12-03	08KH17N13M2T
-	X 10 CrNiMoTi 18 12	1.4573	-	-	X 6 CrNiMoTi 1713	-	320S33	X 6 CrNiMoTI 17 13 3	X 6 CrNiMoTi 17-12-03	10KH17N13M2T
-	X 6 CrNiMoNb 17 12 2	1.458	Z 6 CNDNb 17-12	-	X 6 CrNiMoNb 1712	-	-	X 6 CrNiMoNb 17 12 2	-	08KH16N13M2B
-	X 10 CrNiMoNb 18 12	1.4583	-	-	X 6 CrNiMoNb 1713	-	-	X 6 CrNiMoNb 17 13 3	-	09KH16N15M3B

Stainless Steel Sheet and Coil - Type 410

Frequently Asked Questions (FAQ)

What is 410 stainless steel sheet and coil?

410 stainless steel is a basic martensitic stainless steel that provides high strength and hardness combined with moderate corrosion resistance. It is commonly used for anti-oxidation applications where high mechanical properties are required.

Is 410 stainless steel magnetic?

Yes, 410 stainless steel is magnetic in both the annealed and hardened conditions. However, some elements of standard product lines may start non-magnetic but turn slightly magnetic when cold-worked.

What are the mechanical properties of 410 stainless steel?

Standard 410 stainless steel offers a minimum tensile strength of 480 MPa, minimum yield strength of 275 MPa (0.2% Proof), minimum elongation of 16% in 50mm, and a maximum hardness of 92 Rockwell B or 201 Brinell.

What finishes are available for 410 stainless steel sheets?

Common options include Cold Rolled No. 2B finish, Bright Annealed (BA), Hairline (HL), as well as polished No. 3 and No. 4 finishes. Standard options can also be provided paper-interleaved or vinyl-masked for gauges 22 and heavier.

What are the main applications for 410 stainless steel?

Due to its strength and moderate corrosion resistance, it is widely used in rapid transit cars, retractor springs, hose clamps, conveyors, kitchen cutlery, fasteners, furnace parts, and heat exchangers.

Which standards do these 410 stainless steel products conform to?

They conform to international standards including ASTM A240/A480, ASME SA-240, ASTM A262 Prac E, JIS G4304/G4305, and equivalent DIN, EN, and GOST standards.
